Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

501 / 543

Circuit-breakers, fuses
Fuses, fuse adapters and screw-on caps
2010 CA08103002Z-EN
19/47
Fuses, fuseadapters and screw-oncaps
Rated uninterrupted
current
Fuse link Part no.
Article no.
Price
See price
list
Std. pack
Iu
A Size
Fuse links utilization category gG (gL)
• Snap-fit on DIN rail
• In a plastic box in the color of the
indicator
2 D01 Z-D01/SE-2
288934
12 off
4 Z-D01/SE-4
288935
6 Z-D01/SE-6
288936
10 Z-D01/SE-10
288937
13 Z-D01/SE-13
288938
16 Z-D01/SE-16
288939
20 Z-D02/SE-20
288940
25 Z-D02/SE-25
288941
32 Z-D02/SE-32
288942
35 Z-D02/SE-35
288943
40 Z-D02/SE-40
288944
50 Z-D02/SE-50
288945
63 Z-D02/SE-63
288946
Adapter sleeves
• Snap-fit on DIN rail
• In a plastic box in the color of the
indicator
2 D01 Z-D01/PE-2
288909
12 off
4 Z-D01/PE-4
288910
6 Z-D01/PE-6
288911
10, 13 Z-D01/PE-10
288912
20 Z-D02/PE-20
288913
25 Z-D02/PE-25
288914
35, 32 Z-D02/PE-35
288915
40 Z-D02/PE-40
288916
50 Z-D02/PE-50
288917
• D01 for fuse base D02 and fuse switch-
disconnector D02
2 D02-D01 Z-D02-D01/PE-2
263112
4 Z-D02-D01/PE-4
263113
6 Z-D02-D01/PE-6
263150
10, 13 Z-D02-D01/PE-10
263151
16 Z-D02-D01/PE-16
263152
Screw caps
– Max. 16 D01 Z-D01/SK
100650
20 off
Max. 63 D02 Z-D02/SK
100651
20 off
Retaining spring
• For inserting D01 fuses links in the
screw cap Z‐D02/SK
D02-D01 Z-D02/SIKA-HF
263149
50 off
Z-DO.../SE, Z-DO.../PE, Z-DO.../SK HPL19047EN
