19/16 Circuit-breakers, fuses
Residual-current protective modules for FAZ and AZ, leakage current meter
2010 CA08103002Z-EN
www.eaton.comResidual-currentprotectivemodules for FAZandAZ, leakagecurrentmeter
2 pole
4 pole
Rated
uninterrupted
current
Part no.
Article no.
Price
See price
list
Part no.
Article no.
Price
See price
list
Std. pack
I
u
A
Residual-current protective modules for
FAZ
Rated fault current
I
ΔN
= 30 mA
40
FIM-40/2/0.03-A
278510
FIM-40/4/0.03-A
278514
1 off
Rated fault current
I
ΔN
= 30 mA
63
FIM-63/2/0.03-A
278512
FIM-63/4/0.03-A
278516
Rated fault current
I
ΔN
= 300 mA
40
FIM-40/2/0.3-A
278511
FIM-40/4/0.3-A
278515
Rated fault current
I
ΔN
= 300 mA
63
FIM-63/2/0.3-A
278513
FIM-63/4/0.3-A
278517
2 pole
4 pole
4 pole
Selective
Rated
uninterrupted
current
Part no.
Article no.
Price
See price
list
Part no.
Article no.
Price
See price
list
Part no.
Article no.
Price
See price
list
Std. pack
I
u
A
Residual-current protective modules for
AZ
Rated fault current
I
ΔN
= 30 mA
80
AZFIMP-4-80-0,03
255484
1 off
Rated fault current
I
ΔN
= 30 mA
125
AZFIMP-4-125-0,03
255488
Rated fault current
I
ΔN
= 300 mA
80
AZFIMP-2-80-0,3
255477
AZFIMP-4-80-0,3
255485
AZFIMS-4-80-0,3
255492
Rated fault current
I
ΔN
= 300 mA
125
AZFIMP-2-125-0,3
255481
AZFIMP-4-125-0,3
255489
AZFIMS-4-125-0,3
255495
Notes
FIM-…/2/…
FIM-…/4/…
AZFIMP-2-…
AZFIMP-4-…
AZFIMS-4-…
Pole
Rated operational
current
Response value
Earth-fault release
Part no.
Article no.
Price
See price
list
Std. pack
I
n
I
Δn
A
A
Leakage current meter
• 4 pole, can also be used as 2 and 3 pole
• Electronic operation (independent of mains voltage)
•
, non-delayed
• Type G or part no. S can be set
• ￫19/55
4 pole
40
0.03
0.1
0.3
0.5
1.0
PDIM-40/4
111760
1 off
4 pole
100
0.03
0.1
0.3
0.5
1.0
PDIM-100/4
111761
1 off
2' 4'
2 4
H
T
2' 4' 6' 8'N
2 4 6 8N
H
T
1' 3'/N 13
2' 4'/N 14
H
T
1'
7'/N 13
2'
3'
4'
5'
6' 8'/N 14
H
T
FIM, AZFIM, PDIM
