Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

468 / 543

19/14 Circuit-breakers, fuses
Miniature circuit-breakers (MCB)
2010 CA08103002Z-EN
Miniaturecircuit-breakers (MCB)
1 pole 2 pole 3 pole
With 2 protected poles With 3 protected poles
Rated
operational
current
Part no.
Article no.
Price
See price
list
Std.
pack
Part no.
Article no.
Price
See price
list
Std.
pack
Part no.
Article no.
Price
See price
list
Std.
pack
In
A
AZ miniature circuit-breakers
Characteristic C
Response current of short-circuit
release
5 - 10 x In
Switching capacity 15 - 25 kA
(IEC/EN 60947-2)
20 AZ-C20
211769
12 off AZ-2-C20
211770
2 off AZ-3-C20
211771
1 off
25 AZ-C25
211774
12 off AZ-2-C25
211775
2 off AZ-3-C25
211776
1 off
32 AZ-C32
211779
12 off AZ-2-C32
211780
2 off AZ-3-C32
211781
1 off
40 AZ-C40
211784
12 off AZ-2-C40
211785
2 off AZ-3-C40
211786
1 off
50 AZ-C50
211789
12 off AZ-2-C50
211790
2 off AZ-3-C50
211791
1 off
63 AZ-C63
211794
12 off AZ-2-C63
211795
2 off AZ-3-C63
211796
1 off
80 AZ-C80
211799
12 off AZ-2-C80
211800
2 off AZ-3-C80
211801
1 off
100 AZ-C100
211804
12 off AZ-2-C100
211805
2 off AZ-3-C100
211806
1 off
125 AZ-C125
211809
12 off AZ-2-C125
211810
2 off AZ-3-C125
211811
1 off
Characteristic D
Instantaneous release
response current 10 - 20 x In
Switching capacity 15 - 25 kA
(IEC/EN 60947-2)
50 AZ-D50
211814
12 off AZ-2-D50
211815
2 off AZ-3-D50
211816
1 off
63 AZ-D63
211818
12 off AZ-2-D63
211819
2 off AZ-3-D63
211820
1 off
80 AZ-D80
211822
12 off AZ-2-D80
211823
2 off AZ-3-D80
211824
1 off
100 AZ-D100
211826
12 off AZ-2-D100
211827
2 off AZ-3-D100
211828
1 off
2
1
2
1
4
3
2 4 6
1 3 5
AZ HPL19014EN
