Miniature circuit-breakers (MCB)
4 pole 4 pole
With 4 protected poles With 3 protected poles,
N switching with poles
Part no.
Article no.
Price
See price
list
Std. pack Part no.
Article no.
Price
See price
list
Std. pack Notes
AZ-4-C20
211772
1 off AZ-3N-C20
211773
1 off
AZ-4-C25
211777
1 off AZ-3N-C25
211778
1 off
AZ-4-C32
211782
1 off AZ-3N-C32
211783
1 off
AZ-4-C40
211787
1 off AZ-3N-C40
211788
1 off
AZ-4-C50
211792
1 off AZ-3N-C50
211793
1 off
AZ-4-C63
211797
1 off AZ-3N-C63
211798
1 off
AZ-4-C80
211802
1 off AZ-3N-C80
211803
1 off
AZ-4-C100
211807
1 off AZ-3N-C100
211808
1 off
AZ-4-C125
211812
1 off AZ-3N-C125
211813
1 off
AZ-3N-D50
211817
1 off
AZ-3N-D63
211821
1 off
AZ-3N-D80
211825
1 off
AZ-3N-D100
211829
1 off
4 6
5 3
2
1
8
7
2 4 6
5
N
N 3 1
For switching capacity refer to Technical Data
Accessories Page
Auxiliary contacts, shunt releases ￫19/24
Mounting accessories ￫19/25
1 pole
Depth 75 mm
Width 27 mm
2 pole
Depth 75 mm
Width 54 mm
3 pole
Depth 75 mm
Width 81 mm
4 pole; 3 pole + N
Depth 75 mm
Width 108 mm
