SmartWire-Darwin
SWD input/output modules
2010 CA08103002Z-EN
17/187
NZM-XSWD-704
Digital inputs
Number 2
Input current mA Typically 4 at 24 V DC
Voltage level to IEC/EN 61131-2
Limit value type 1 Low < 5 V DC; High > 15 V DC
Input delay High → Low typically < 0.2 ms
Low → High typically < 0.2 ms
Status display inputs LED Yellow
Digital semiconductor outputs
Number 2
Output current A 0.2 at 24 V DC
Short-circuit tripping current A –
Lamp load RLL W –
Overload proof Yes, with diagnostics
Switching capacity EN 60947-5-1 utilization category DC-13
Relay outputs
Number –
Contact type –
Operations
Utilization category AC-1, 250 V, 6 A –
Utilization category AC-15, 250 V, 3 A –
Utilization category DC-13, 24 V, 1 A –
Safe disconnection V AC –
Minimum load current mA –
Response/reset time ms –
Bounce duration ms –
Short-circuit protection –
Status display outputs LED –
Potential isolation
Inputs for SmartWire-Darwin Yes
Semiconductor outputs to SmartWire-Darwin Yes
Semiconductor outputs to inputs –
Relays to SmartWire-Darwin –
Relays to inputs –
Relays to relays –
NZM-XSWD
