Circuit-breakers, switch-disconnectors
Fieldbus interface
2010 CA08103002Z-EN
17/185
EASY221-CO EASY222-DN NZM-XDMI-DPV1
Insulation resistance
Clearances and creepage
distances
EN 50178, UL 508, CSA C22.2, No. 142
Insulation resistance EN 50178
Power supply
Rated operating voltage Ue V 24 (-15/+20 %) 24 (-15/+20 %) 24 (-15/+20 %)
Permissible range V DC 20.4 – 28.8 20.4 – 28.8 20.4 – 28.8
Ripple % < 5 < 5 < 5
At 24 V DC mA typ. 200 typ. 200 typ. 200
Voltage dips (IEC/EN 61131-2) ms 10 10 10
Heat dissipation at 24 V DC W 4.8 4.8 4.8
Polarity reversal protection
Power supply Yes Yes Yes
LED indicators
Power supply RUN LED (RUN): green Module status LED (MS): green Power LED (POW): green
LED display LED ERROR (ERR): red Network status LED (NS):
red/green
PROFIBUS-DP LED (BUS): red
Network
Terminal type RJ45 5 pole, pluggable screw
terminal
SUB-D 9 pole, socket
Potential isolation Between bus and power supply
(simple), between bus and
power supply and
NZM-XDMI612 (safe isolation)
Between bus and power supply
(simple), between bus and
power supply and
NZM-XDMI612 (safe isolation)
Between bus and power supply
(simple), between bus and
power supply and
NZM-XDMI612
Function CANopen slave DeviceNet slave PROFIBUS-DP slave
Interface CAN CAN RS 485
Bus protocol CANopen DeviceNet PROFIBUS-DP
Baud rates Automatic search up to
1 MBit/s
Automatic search up to
500 kBit/s
Automatic search up to
12 MBit/s
Bus terminating resistors Separate external bus
termination required (120 O)
NZM-XDMI612
Separate external bus
termination required (120 O)
NZM-XDMI612
Separate external bus
termination required
Bus addresses 1 – 127 addressed via display 0 – 63 addressed via display 1 – 126 via DMI
Services
Cyclical All data R1 – R16, S1 – S8 All data R1 – R16, S1 – S8 StatusOn/Off,tripped (detailed),
load early warnings, phase
currents I1/I2/I3[A], remote
operator acutation, display/
operation NZM-XDMI612,
inputs/outputs, motor starter
functions
Acyclical Read/write, real-time, day,
summer/winter time,
all parameters of the
easy function relay
Read/write, real-time, day,
summer/winter time,
all parameters of the
easy function relay
Display/match protection
protection settings, event list,
identification, hours of
operation, switching
operations, time
EASY..., NZM-...
