Circuit-breakers, switch-disconnectors
Data Management Interface (DMI module)
2010 CA08103002Z-EN
www.eaton.com17/183
DataManagement Interface (DMImodule)
DMI
General
Dimensions (W x H x D)
mm 107.5 x 90 x 53
Modular spacing (space units)
6 SU (space units) wide
Weight
kg
0.3
Mounting
Top-hat rail IEC/EN 60715, 35 mm
Ambient climatic conditions
Operating ambient temperature
°C
0 to +55
Built-in position
Horizontal/vertical
Condensation
Prevent condensation by means of suitable measures
LCD display (clearly legible)
°C
0 to +55
Storage/transport
°C
-40 to +70
Relative humidity, non-condensing (IEC/EN 60068-2-30)
% 5...95
Air pressure (in operation)
hPa
795...1080
Corrosion resistance
IEC/EN 60068-2-42
4 days
SO
2
cm
3
/m
3
10
IEC/EN 60068-2-43
4 days
H
2
S
cm
3
/m
3
1
Ambient mechanical conditions
Pollution degree
2
Degree of protection IEC/EN 60529
IP20
Vibrations (IEC/EN 60068-2-6)
Constant amplitude 0.15 mm
Hz
10...57
Constant acceleration, 2 g
Hz
57...150
Mechanical shock resistance (IEC/EN 60068-2-27) semi-sinusoidal 15 g/11
Shocks 18
Drop IEC/EN 60068-2-31
Drop
height
mm 50
Free fall, packaged (IEC/EN 60068-2-32)
m
1
Power supply
Rated operating voltage
U
e
V DC 24
Permissible range
V DC 20.4...28.8
Residual ripple
% ≦ 5
Input current at 24 V DC
mA
210
Voltage dips (IEC/EN 61131-2)
ms
10
Power loss at 24 V DC
W 5
NZM…-XU, NZM…-XA…
