Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

280 / 543

17/184 Circuit-breakers, switch-disconnectors
Fieldbus interface
2010 CA08103002Z-EN
Fieldbus interface EASY221-CO EASY222-DN NZM-XDMI-DPV1
General
Standards EN 55011, EN 55022, EN 61000-4, IEC 60068-2-6, IEC 60068-2-27
Dimensions (W x H x D) mm 35.5 x 90 x 58
(2 space units)
35.5 x 90 x 58
(2 space units)
35.5 x 90 x 58
(2 space units)
Weight kg 0.15 0.15 0.15
Mounting Top-hat rail EN 50022, 35 mm or screw fixing using fixing brackets
ZB4-101-GF1 (accessories)
Terminal capacity
Solid mm2 0.2x4 (AWG 22 – 12) 0.2x4 (AWG 22 – 12) 0.2x4 (AWG 22 – 12)
Flexible with ferrule mm2 0.2x2.5 (AWG 22 – 12) 0.2x2.5 (AWG 22 – 12) 0.2x2.5 (AWG 22 – 12)
Standard screwdriver mm 3.5 x 0.8 3.5 x 0.8 3.5 x 0.8
Max. tightening torque Nm 0.6 0.6 0.6
Ambient climatic conditions
Operating ambient temperature °C -25 to 55, low temperatures to IEC 60068-2-1,
high temperatures to IEC 60068-2-2
Condensation Prevent condensation by means of suitable measures
Storage °C 40 – 70 40 – 70 40 – 70
Relative humidity, non-condensing (IEC/EN 60068-2-30) % 5 – 95 5 – 95 5 – 95
Air pressure (in operation) hPa 795 – 1080 795 – 1080 795 – 1080
Corrosion resistance
IEC/EN 60068-2-42 4 days SO 2 cm3 /m3 10 10 10
IEC/EN 60068-2-43 4 days H2S cm3 /m3 1 1 1
Ambient mechanical conditions
Pollution degree 2 2 2
Degree of protection (IEC/EN 60529) IP20 IP20 IP20
Vibrations (IEC/EN 60068-2-6)
Constant amplitude 0.15 mm Hz 10 – 57 10 – 57 10 – 57
Constant acceleration, 2 g Hz 57 – 150 57 – 150 57 – 150
Mechanical shock resistance (IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks 18 18 18
Drop (IEC/EN 60 068-2-31) Drop height mm 50 50 50
Free fall, packaged (IEC/EN 60068-2-32) m 1 1 1
Mounting position horizontal x
vertical
horizontal x
vertical
horizontal x
vertical
Electromagnetic compatibility (EMC)
Electrostatic discharge (IEC/EN 61000-4-2, Level 3, ESD)
Air discharge kV 8 8 8
Contact discharge kV 6 6 6
Electromagnetic fields (IEC/EN 61000-4-3, RFI) V/m 10 10 10
Radio interference suppression (EN 55011) EN 55011 Class B
EN 55022 Class B
EN 55011 Class A
EN 55022 Class A
Burst impulse (IEC/EN 61000-4-4, Level 3)
Supply cables kV 2 2 2
Signal cables kV 2 2 2
High-energy pulses (surge)
(IEC/EN 61000-4-5, Level 2)
kV 0.5 (supply cables, symmetrical)
Immunity to line-conducted interference
(IEC/EN 61000-4-6)
V 10 10 10
EASY22..., NZM-XDMI
