11/26

Electronic relays

Measuring and monitoring relays

2010

CA08103002Z-EN

www.eaton.com

EMR

EMRMeasuringandmonitoring relays

EMR5-A300-1-C

EMR5-A400-1

Input circuit, measuring circuit

L1,L2,L3

L1,L2,L3

Rated control voltage, monitored voltage

U

s

3

x 160 - 300 V AC

3

x 300 - 500 V AC

Typical current/power consumption

25

mA/10 VA/230 V AC

25

mA/18 VA/400 V AC

Rated control voltage tolerance

U

s

%

-15 -

+10

-15 -

+10

Rated frequency

Hz

50/60

50/60

Frequency range

Hz

45 - 65

45 - 65

Measuring circuit

Monitoring functions

Phase failure

Yes

Yes

Phase sequence

Yes

Yes

Automatic phase sequence correction

No

No

Asymmetry

Yes

Yes

Overvoltage/undervoltage

No

No

Neutral conductor

No

No

Measuring range

Overvoltage

No

No

Undervoltage

No

No

Asymmetry

2 - 25 %

of phase voltage mean value

Adjustable threshold values

Overvoltage

No

No

Undervoltage

No

No

Imbalance (disconnection value)

Adjustable within measuring

range

Adjustable within measuring

range

Hysteresis relative to threshold value

Overvoltage/undervoltage

No

No

Asymmetry

Fixed 20 %

Fixed 20 %

Rated frequency of measuring signal

Hz

50/60

50/60

Frequency range of measuring signal

Hz

45 - 65

45 - 65

Maximum monitoring cycle

ms

100

100

Measuring error within rated control voltage

tolerance

Measuring error within temperature range

Measurement method

True RMS value measurement

True RMS value measurement

Timing circuit

On-delay

T

s

ms

Fixed 200

Fixed 200

Response delay

T

v

s

On-delayed: none = 0;

adjustable 0.1 - 30

On-delayed: none = 0;

adjustable 0.1 - 30

Timeout error within rated control voltage tolerance

%

≤ 0.5

≤ 0.5

Timeout error within temperature range

% /

°C

≤ 0.06

≤ 0.06

Repetition accuracy

(

constant parameters)

%

< ±0.2

< ±0.2

Operating status indication

Relay status R: yellow LED

See instructional leaflet

See instructional leaflet

Output circuits

Output circuits

15-16/18, 25-26/28

15-16/18, 25-26/28

Output type

2

x 1 relay (changeover contact)

2

x 1 relay (changeover contact)

Operating principle

Closed-circuit principle: output relays drop out when value above/

below set threshold value

Contact material

AgNi alloy, Cd-free

AgNi alloy, Cd-free

Rated operating voltage (VDE 0110, IEC 60947-1)

V

250

250

Minimum switching voltage/minimum switching current

No

24

V/10 mA

24

V/10 mA

Minimum switching duty

V/mA

24/10

24/10

Maximum switching voltage

→Page 11/21

→Page 11/21

Rated operational current (IEC 60947-5-1)

AC12 (resistive) at 230 V

A

4

4

AC15 (inductive) at 230 V

A

3

3

DC12 (resistive) at 24 V

A

4

4

DC13 (inductive) at 24 V

A

2

2

Rating data AC (UL 508)

Utilization category (Control Circuit Rating Code)

B 300

B 300

Max. rated operational voltage

V AC

300

300

Max. thermal uninterrupted current at B 300

A

5

5

Max. input/output rating (N/O / N/C) for B 300

VA

3600/360

3600/360

Mechanical lifespan

Operations 30 x 10

6

30

x 10

6

Electrical lifespan (AC12, 230 V, 4 A)

Operations 0.1 x 10

6

0.1

x 10

6
