Electronic relays

Measuring and monitoring relays

2010

CA08103002Z-EN

www.eaton.com

EMR

Measuringandmonitoring relaysEMR

EMR5-N080-1-B

EMR4-N100-1-B

EMR4-N500-2-B

EMR4-N500-2-A

Input circuit

Rated control voltage

U

S

-

power consumption:

A1 - A2

220 - 240

V AC

approx. 1.5 VA

220 - 240

V AC

approx. 4 VA

220 - 240

V AC

approx. 3 VA

24 - 240

V AC/DC

approx. 2 VA/W

Tolerance of rated control voltage U

S

-15 % - 10 %

-15 % - 10 %

-15 % -

+10 %

-15 % -

+10 %

Rated frequency

50 - 60

Hz

50 - 60

Hz

50 - 60

Hz or DC

50 - 60

Hz or DC

Duty factor (DF)

100 %

100 %

100 %

100 %

Measuring circuit

MAX-MIN-C

MAX-MIN-C

MAX-MIN-C

MAX-MIN-C

Monitoring functions

Level control

Level control

Level control

Level control

Response sensitivity

5 - 100

kΩ, adjustable

5 - 100

kΩ, adjustable

250

Ω - 5 kΩ, adjustable 250 Ω - 5 kΩ, adjustable

Maximum electrode voltage

30

V AC

30

V AC

20

V AC

20

V AC

Maximum electrode current

1

mA

1

mA

8

mA

8

mA

Electrode supply cable

Cable capacity max.

10

nF

10

nF

200

nF

200

nF

Cable length max.

100

m

100

m

1000

m

1000

m

Response sensitivity

2.5-50

kΩ, adjustable

2.5-50

kΩ, adjustable

Maximum electrode voltage

20

V AC

20

V AC

Maximum electrode current

2

mA

2

mA

Electrode supply cable

Cable capacity max.

20

nF

20

nF

Cable length max.

100

m

100

m

Response sensitivity

25 - 500

kΩ, adjustable 25 - 500 kΩ, adjustable

Maximum electrode voltage

20

V AC

20

V AC

Maximum electrode current

0.5

mA

0.5

mA

Electrode supply cable

Cable capacity max.

4

nF

4

nF

Cable length max.

20

m

20

m

Timing circuit

Release delay

Approx. 250 ms

Approx. 250 ms

Delay time

0.1 - 10

s, adjustable, on-

delay without off-delay

0.1 - 10

s, adjustable, on-

delay without off-delay

Operating status indication

Control voltage

U: green LED

U: green LED

U: green LED

U: green LED

Output relay energized

R MAX/MIN: yellow LED

Alarm relay AL1

R AL1: yellow LED

U: green LED

U: green LED

Alarm relay AL2

R AL2: yellow LED

R: yellow LED

R: yellow LED

Output circuits

Output circuits

11-12/14, 21-22, 31-32

11-12/14, 21-22, 31-32

15-16/18, 25-26/28

15-16/18, 25-26/28

Output type

1

changeover contact,

1

normally closed

contact + 1 normally

open contact

1

changeover contact,

1

normally closed contact

+ 1 normally open contact

Two changeover

contacts

Two changeover

contacts

Operating principle

Live current principle

1)

Open-

1)

and

closed-circuit principle

2)

Live current principle

1)

Live current principle

1)

Contact material

AgCdO

AgCdO

AgCdO

AgCdO

Rated voltage (VDE 0110, IEC 60947-1)

250

V

250

V

400

V

400

V

Maximum switching voltage

250

V

250

V

400

V

400

V

Rated operational current (IEC 60947-5-1)

AC12 (resistive) 230 V

4

A

4

A

5

A

5

A

AC15 (inductive) 230 V

3

A

3

A

3

A

3

A

DC12 (resistive) 24 V

4

A

4

A

5

A

5

A

DC13 (inductive) 24 V

2

A

2

A

2

A

2

A

Notes

1)

Output relays pick up when value above/below set threshold value

2)

Output relays drop out when value above/below set threshold value
