Electronic relays
Measuring and monitoring relays
2010 CA08103002Z-EN
EMR 11/25
EMR4-F500-2
Environmental data
Ambient temperature range, operation/storage -20 - +60 °C / -40 - +85 °C
Climatic testing (IEC 68-2-30) 24 h cycle, 55 °C, 93 % rel., 96 h
Operating safety (IEC 68-2-6) 4 g
Mechanical strength (IEC 68-2-6) 6 g
Insulation data
Rated voltage between supply, measuring, and output circuits
(VDE 0110, IEC 60947-1)
500V
Rated impulse withstand voltage Uimp between all insulated circuits
(VDE 0110, IEC 664)
2.5 kV, 50 Hz, 1 min.
Test voltage between all insulated circuits (routine test) 4 kV, 50 Hz, 1 min.
Pollution degree (VDE 0110, IEC 664, IEC 255-5) 3
Overvoltage category (VDE 0110, IEC 664, IEC 255-5) III
Directives and standards
Product standard IEC 255-6, EN 60255-6
Low-Voltage Directive 2006/95/EC
EMC Directive 2004/108/EC
Electromagnetic compatibility
Noise immunity EN 61000-6-2
Electrostatic discharge (ESD) IEC/EN 61000-4-2 Level 3 (6 kV/8 kV)
Electromagnetic field (immunity to RF interference)
IEC/EN 61000-4-3
Level 3 (10 V/m)
Fast transients (burst) IEC/EN 61000-4-4 Level 3 (2 kV/5 kHz)
High-energy pulses (surge) IEC 1000-4-5, EN 61000-4-5 Level 4 (2 kV L-L)
Cable-borne HF IEC 100-4-6, EN 61000-4-6 Level 3 (10 V)
Interference emission EN 61000-6-4
