Electronic relays

Measuring and monitoring relays

2010

CA08103002Z-EN

www.eaton.com

EMR

Measuringandmonitoring relaysEMR

Technical data

EMR4-I1-1-A

EMR4-I15-1-A

EMR4-I15-1-B

Input circuit, power supply circuit A1-A2

Rated control voltage U

S

-

power consumption:

A1-A2

24 - 240

V AC/DC

24 - 240

V AC/DC

220 - 240

V AC

Tolerance of rated control voltage U

S

-15 -

+10 %

-15 -

+10 %

-15 -

+10 %

Rated frequency

AC versions

50/60

Hz

50/60

Hz

50/60

Hz

AC/DC versions

50/60

Hz or DC

50/60

Hz or DC

50/60

Hz or DC

Current/power consumption

24

V DC

30

mA/0.75 W

30

mA/0.75 W

115

V AC

24

mA/2.6 VA

24

mA/2.6 VA

230

V AC

11

mA/2.6 VA

11

mA/2.6 VA

12

mA/2.6 VA

Duty factor (DF)

100 %

100 %

100 %

Mains failure buffering

20

ms

20

ms

20

ms

Transient overvoltage protection

Varistors

Varistors

Varistors

Input circuit measuring circuit B1/B2/B3-C

Monitoring functions

Overcurrent or

undercurrent monitoring

can be configured

Overcurrent or

undercurrent monitoring

can be configured

Overcurrent and

undercurrent monitoring

Measurement method

True RMS value measurement, any curve shapes

Measuring inputs

Terminal assignment B1 - C

Measurement ranges AC/DC

3 - 30

mA

0.3 - 1.5

A

0.3 - 1.5

A

Input resistance

3.3

Ω

0.05

Ω

0.05

Ω

Pulse overload capacity t < 1 s

500

mA

15

A

15

A

Long-term overload

50

mA

2

A

2

A

Measuring inputs

Terminal assignment B2 - C

Measurement ranges AC/DC

10 - 100

mA

1 - 5

A

1 - 5

A

Input resistance

1

Ω

0.01

Ω

0.01

Ω

Pulse overload capacity t < 1 s

1

A

50

A

50

A

Long-term overload

150

mA

7

A

7

A

Measuring inputs

Terminal assignment B3 - C

0.1 - 1

A

3 - 15

A

3 - 15

A

Measurement ranges AC/DC

0.1

Ω

0.0025

Ω

0.0025

Ω

Input resistance

10

A

100

A

100

A

Pulse overload capacity t < 1 s

1.5

A

17

A

17

A

Long-term overload

Threshold value(s)

Adjustable within specified measuring range

Threshold value setting accuracy

0.1

0.1

0.1

Repetition accuracy (constant parameters)

±0.07 % of full-scale value ±0.07 % of full-scale value ±0.07 % of full-scale value

Hysteresis relative to threshold value

3 - 30 %

adjustable

3 - 30 %

adjustable

3 - 30 %

adjustable

Frequency range of measuring signal

DC/15 Hz - 2 kHz

DC/15 Hz - 2 kHz

DC/15 Hz - 2 kHz

Rated frequency range of measuring signal

DC/50 - 60 Hz

DC/50 - 60 Hz

DC/50 - 60 Hz

Maximum response time

AC: 80 ms/DC: 120 ms

AC: 80 ms/DC: 120 ms

AC: 80 ms/DC: 120 ms

Measuring error within control voltage tolerance

≤ 0.5 %

≤ 0.5 %

≤ 0.5 %

Measuring error within temperature range

≤ 0.06 %/°C

≤ 0.06 %/°C

≤ 0.06 %/°C

Timing circuits

Release delay T

v

0

or 0.1 - 30 s adjustable

0

or 0.1 - 30 s adjustable

0

or 0.1 - 30 s adjustable

Repetition accuracy (constant parameters)

None

±0.07 % of full-scale value ±0.07 % of full-scale value

Time error within control voltage tolerance

≤ 0.5 %

≤ 0.5 %

≤ 0.5 %

Timeout error within temperature range

≤ 0.06 %/°C

≤ 0.06 %/°C

≤ 0.06 %/°C

Operating status indication

Control voltage U/T: green LED

Continuous light: control voltage present; slow flashing: trip delay T

v

active

Measured value I: red LED

Continuous light: overcurrent; slow flashing: undercurrent

Relay status R: yellow LED

Continuous light: relay picked up, no storage

Slow flashing: duty factor long: relay picked up, active storage

Slow flashing: duty factor short: relay dropped out, active storage

Output circuits

11(15) - 12(16)/14(18), 21(25) -

22(26)/24(28) -

relays

11(15) - 12(16)/14(18), 21(25) -

22(26)/24(28) -

relays

11(15) - 12(16)/14(18), 21(25) -

22(26)/24(28) -

relays

Output type

Two changeover contacts Two changeover contacts Two changeover contacts

Operating principle

Open-circuit principle: Output relays pick up when actual value exceeds or is below set

threshold value.
