2010

CA08103002Z-EN

Electronic relays

Timing relays

DILET, ETR

Information relevant for export to

North America

Product Standards IEC/EN 61812-1; IEC/

EN 60947-5-1; UL 508;

CSA-22.2 No. 14-05; CE

marking

UL File No.

E29184

UL CCN

NKCR, NKCR7

CSA File No.

UL report valid

CSA Class No.

3211-03

NA Certification

UL Listed, Certified by

UL for use in Canada

Degree of Protection IEC: IP20, UL/CSA

Type: -

Product Standards IEC/EN 61812-1; IEC/

EN 60947-5-1; UL 508;

CSA-22.2 No. 14-05; CE

marking

UL File No.

E29184

UL CCN

NKCR, NKCR7

CSA File No.

UL report valid

CSA Class No.

3211-03

NA Certification

UL Listed, Certified by

UL for use in Canada

Degree of Protection IEC: IP20, UL/CSA

Type: -

Function

Terminal marking according to EN 50042

Fixed

11,

On-delayed

A1

A2

15

16 18

Function

Terminal marking according to EN 50042

Fixed

12,

Off-delayed

A1

A2

B1

15

16 18

Function

Terminal marking according to EN 50042

Fixed

21,

Fleeting contact on

energization

A1

A2

16

15

18

Function

Terminal marking according to EN 50042

Fixed

42,

Flashing, pulse initiating

A1

A2

16

15

18

Function

Terminal marking according to EN 50042

Fixed

44,

Flashing, 2 variable times

Can be set to either pulse or

pause initiating

A1

A2

B1

15

16 18

Function

Terminal marking

according to EN 50042

Function

Terminal marking

according to EN 50042

Adjustable

11,

On-delayed

21,

Fleeting contact on energization

42,

Flashing, pulse initiating

43,

Flashing, pause initiating

Adjustable

12,

Off-delayed

22,

Fleeting contact on

de-energization

82,

Pulse shaping

A1

A2

16

15

18

A1

A2

B1

15

16 18

Function

Terminal marking according to EN 50042

Fixed

11,

On-delayed

A1

A2

16

15

18 26

25

28

Function

Terminal marking according to EN 50042

Fixed

12,

Off-delayed

A1

A2

B1

16

15

18 26

25

28

Function

Terminal marking

according to EN 50042

Function

Terminal marking

according to EN 50042

Adjustable

11,

On-delayed

21,

Fleeting contact on energization

42,

Flashing, pulse initiating

43,

Flashing, pause initiating

Adjustable

12,

Off-delayed

22,

Fleeting contact on

de-energization

82,

Pulse shaping

A1

A2

16

15

18 26

25

28

A1

A2

B1

16

15

18 26

25

28

11/7

HPL11007EN
