Electronic relays
Timing relays
DILET
Notes Information relevant for export to North America
Fixed
11, On-delayed
Product Standards IEC/EN 61812-1; IEC/EN 60947-5-1; UL 508;
CSA-22.2 No. 14-05; CE marking
UL File No. E29184
UL CCN NKCR, NKCR7
CSA File No. 12528
CSA Class No. 3211-03
NA Certification UL Listed, CSA Certified
Degree of Protection IEC: IP20, UL/CSA Type: -
Adjustable
11, On-delayed
21, Fleeting contact on energization
42, Flashing
81, Pulse generating
ON-OFF
Adjustable
12, Off-delayed
16, On- and off-delayed
22, Fleeting contact on
de-energization
82, Pulse shaping
ON-OFF
Product Standards IEC/EN 61812-1; IEC/EN 60947-5-1; UL 508;
CSA-22.2 No. 14-05; CE marking
UL File No. E29184
UL CCN NKCR, NKCR7
CSA File No. 12528
CSA Class No. 3211-03
NA Certification UL Listed, CSA Certified
Degree of Protection IEC: IP20, UL/CSA Type: -
11 ON-DELAYED
21 FLEETING CONTACT ON ENERGIZATION
42 FLASHING
81 PULSE GENERATING CONTACT
A1
A2
15
16 18
A1
A2
15
16 18
Cable connection with
Y1/Y2, Z1/Z2
Permissible cable length
(cable unshielded, with
cable cross-section
0.5-1.5 mm2):
Two-core cable 250 m
Two-core cable in the
same cable duct with
mains cable, 50/60 Hz
50 m
A1
A2
Z2 Z1
15
16 18
A1
A2
Z2 Z1
Y1
Y2
15
16 18
A2
A1
16 18
15
Z1 Z2
Information relevant for export to North America
Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA Certified
Degree of Protection UL/CSA part no. 3R, 4X, 12, 13
UL/CSA certification not required
11/3
