11/2 Electronic relays
Timing relays
DILET
2010 CA08103002Z-EN
DILETTiming relays
Rated operational
current AC-11
Conventional
thermal current
Time Range Voltage range Part no.
Article No.
Price
See price
list
Std. pack
230 V 400 V Ith
Ie Ie A
A A
A A
Timing relays DILET
On-delayed
Timing functions￫Page 11/8
Component lifespan￫Page 11/10
3 3 6 1.5 - 30 s 24 - 240 V AC, 50/60 Hz
24 - 240 V DC
DILET11-30-A
048878
1 off
3 3 6 1.5 - 30 s 400 V AC, 50/60 Hz DILET11-30-W
048904
3 3 6 0.05 - 1 s
0.15 - 3 s
0.5 - 10 s
3 - 60 s
0.15 - 3 min
0.5 - 10 min
3 - 60 min
0.15 - 3 h
0.5 - 10 h
3 - 60 h
24 - 240 V AC, 50/60 Hz
24 - 240 V DC
DILET11-M-A
048886
3 3 6 400 V AC, 50/60 Hz DILET11-M-W
048891
Multi-functional with remote potentiometer
Timing functions￫Page 11/8
Component lifespan￫Page 11/10
3 3 6 0.05 - 1s
0.15 - 3 s
0.2217925 - 10 s
3 - 60 s
0.15 - 3 min
0.5 - 10 min
3 - 60 min
0.15 - 3 h
0.5 - 10 h
3 - 60 h
24 - 240 V AC, 50/60 Hz
24 - 240 V DC
DILET70-A
048893
1 off
3 3 6 400 V AC, 50/60 Hz DILET70-W
048899
Resistance Rated power For use with Part no.
Article no.
Price
See price
list
Std. pack
R P
kΩ W
Remote potentiometer, IP66
10 ≦ 0.5 DILET…
ETR4-70
M22-R10K
229491
1 off
10 – DILET…
ETR4-70
M22S-R10K
232233
1 off
Screw adapters
For screw fixing
– – EWDIL
ETS4-VS3
ETR4
CS-TE
095853
10 off
HPL11002EN
