Eaton Industrial Switchgear - xStart switching, protections and actuating motors

2010

CA08103002Z-EN

www.eaton.com

Contactors

Basic devices up to 170 A

AC operation

DC operation

Can be combined

with auxiliary

contact

Part no.

Article no.

Price

See

price list

Part no.

Article no.

Price

See

price list

Std. pack

Notes

DILM32-XHI..

DILA-XHI(V)..

DILM7-10(230V50HZ)

276550

DILM7-10(24VDC)

276565

off

Contacts to EN 50 012.

For all DC operated contactors DILM7 - DILM15 the following

applies:

•

Integrated varistor-suppressor circuit.

For DC operated contactors DILM17 - DILM170 the following

applies:

•

Integrated suppressor circuit in actuating electronics

For AC operated contactors DILM115 - DILM170 the following

applies:

•

Integrated suppressor circuit in actuating electronics

For DILM7-01 – DILM38-01 the following applies:

•

With mirror contact.

Electrical lifespan￫5/91

DILA-XHI(V)..

DILM7-01(230V50HZ)

276585

DILM7-01(24VDC)

276600

DILM32-XHI..

DILA-XHI(V)..

DILM9-10(230V50HZ)

276690

DILM9-10(24VDC)

276705

DILA-XHI(V)..

DILM9-01(230V50HZ)

276725

DILM9-01(24VDC)

276740

DILM32-XHI..

DILA-XHI(V)..

DILM12-10(230V50HZ)

276830

DILM12-10(24VDC)

276845

DILA-XHI(V)..

DILM12-01(230V50HZ)

276865

DILM12-01(24VDC)

276880

DILM32-XHI..

DILA-XHI(V)..

DILM15-10(230V50HZ)

290058

DILM15-10(24VDC)

290073

DILA-XHI(V)..

DILM15-01(230V50HZ)

290093

DILM15-01(24VDC)

290108

DILM32-XHI..

DILA-XHI(V)..

DILM32-XHI11-S

DILM17-10(230V50HZ)

277004

DILM17-10(RDC24)

277018

DILA-XHI(V)..

DILM32-XHI11-S

DILM17-01(230V50HZ)

277036

DILM17-01(RDC24)

277050

DILM32-XHI..

DILA-XHI(V)..

DILM32-XHI11-S

DILM25-10(230V50HZ)

277132

DILM25-10(RDC24)

277146

DILA-XHI(V)..

DILM32-XHI11-S

DILM25-01(230V50HZ)

277164

DILM25-01(RDC24)

277178

DILM32-XHI..

DILA-XHI(V)..

DILM32-XHI11-S

DILM32-10(230V50HZ)

277260

DILM32-10(RDC24)

277274

DILA-XHI(V)..

DILM32-XHI11-S

DILM32-01(230V50HZ)

277292

DILM32-01(RDC24)

277306

DILM32-XHI..

DILA-XHI(V)..

DILM32-XHI11-S

DILM38-10(230V50HZ)

112428

DILM38-10(RDC24)

112442

DILA-XHI(V)..

DILM32-XHI11-S

DILM38-01(230V50HZ)

112456

DILM38-01(RDC24)

112470

Accessories

Page

Overload relay

￫Chapter 6

Suppressor

￫5/54

Auxiliary contact module

￫5/38

Further actuating voltages

￫5/73

Accessories

￫5/56

5/19
