Contactors
2010 CA08103002Z-EN
5/15
Contactors
3 pole
M185A M225A M250 M300A M400 M500 M580 M650 M750 M820 M1000 M1600 H1400 H2000 H2200 H2600
– – – – – – – – – – – – – – – –
￫Page 5/32 ￫Page 5/32 ￫Page 5/32 ￫Page 5/32 ￫Page 5/34
kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
55 70 75 90 125 155 185 205 240 260 315 500 – – – –
90 110 132 160 200 250 315 355 400 450 560 900 – – – –
115 142 157 190 255 345 370 420 480 525 650 1000 – – – –
132 160 180 215 290 360 420 470 550 600 730 1180 – – – –
175 215 240 286 344 344 560 630 720 750 1000 1600 – – – –
108 108 108 132 132 132 600 600 800 800 1000 1770 – – – –
41 51 62 75 92 112 143 161 181 209 260 430 – – – –
75 90 110 132 160 200 250 280 315 355 450 750 – – – –
85 102 125 140 186 229 290 326 367 418 520 830 – – – –
96 116 143 172 214 260 330 370 417 474 590 940 – – – –
127 155 189 229 283 344 440 494 556 633 780 1300 – – – –
108 108 108 132 132 132 509 509 678 678 1000 1650 – – – –
121 139 155 177 221 310 354 376 398 443 443 717 620 886 1075 1269
210 241 268 306 382 535 612 650 689 766 766 1247 1071 1531 1870 2207
243 279 310 354 443 620 709 753 797 886 886 1371 1240 1773 2058 2427
277 317 352 403 503 705 806 856 906 1007 1007 1558 1410 2015 2338 2758
365 419 465 532 664 930 1064 1130 1196 1330 1330 2151 1861 2660 3227 3806
554 635 705 806 1007 1410 1612 1712 1813 2015 2015 2420 2417 3223 4676 5516
A A A A A A A A A A A A A A
337 356 400 430 612 857 980 1041 1102 1225 1225 2200 1714 2450 2700 3185
Contactors
4 pole
MP45 MP63 MP80 MP125 MP160 MP200
￫Page 5/36 ￫Page 5/36 ￫Page 5/36
A A A A A A
45 63 80 125 160 200
DILM, DILH, DILMP
