4/58 Cam switches, switch-disconnectors
2010 CA08103002Z-EN
Emergency
switching
off/emergency stop
For use with Part no.
Article no.
Price
See
price list
Std. pack Notes
Main switch assembly kits
Padlocking feature
only for main switch
Permissible with T0 with up to max. 4 contact units
Permissible with T3 with up to max. 6 contact units
Withredrotary
handle and
yellow locking
collar
As an emergency
switching off/emer-
gency stop device
To IEC/EN 60204-1,
VDE 0113 Part 1
T0-…/E, …/Z, …/I1
T3-…/E, …/Z, …/I2
P1-…/E, …/Z, …/I2
SVB-T0
057892
1 off • For locking the 0 position
• For switches with positions
0 -I at 90°
• Switching angle as front
plate FS908
• Lockable with max.
3 padlocks
T5B-…/E, …/Z, …/I4
T5-.../E, .../Z, .../I5
P3-63/E, …/Z, …/I4
P3-100/E, …/Z, …/I5
SVB-P3
052999
1 off
With black
rotary handle
and black
locking collar
Without emergency
switching off/emer-
gency stop function
T0-…/E, …/Z, …/I1
T3-…/E, …/Z, …/I2
P1-…/E, …/Z, …/I2
SVB-SW-T0
060265
1 off • For locking the 0 position
• For locking the I position
when required
• Lockable with max.
3 padlocks T5B-…/E, …/Z, …/I4
T5-.../E, .../Z, .../I5
P3-63/E, …/Z, …/I4
P3-100/E, …/Z, …/I5
SVB-SW-P3
062491
1 off
Main switch assembly kits with PE terminal and N terminal
Padlocking feature
only for main switch
Permissible with T0 with up to max. 4 contact units
Permissible with T3 with up to max. 6 contact units
Withredrotary
handle and
yellow locking
collar
As an emergency
switching off/emer-
gency stop device
To IEC/EN 60204-1,
VDE 0113 Part 1
T0-…/E, …/Z
T3-…/E, …/Z
V/EA/SVB-T0
062638
1 off • For converting flush
mounting switch T…/E into
flush mounting main switch
T…/EA/SVB…
• For converting rear
mounting switch T…/Z
(with FS908 front plate) into
interlocked rear mounting
main switch T…/V/SVB
T5(B)-…/E, …/Z V/EA/SVB-T5
045065
1 off
With black
rotary handle
and black
locking collar
Without emergency
switching off/emer-
gency stop function
T0-…/E, …/Z
T3-…/E, …/Z
V/EA/SVB-SW-T0
065011
1 off
T5(B)-…/E, …/Z V/EA/SVB-SW-T5
045064
1 off
Thumb-grips
Black – T0-…/E, …/EZ, …/IVS, …/Z, …/I1
T3-…/E, …/EZ, …/IVS, …/Z, …/I2
P1-…/E, …/EZ, …/IVS, …/Z, …/I2
KNB-T0
038909
10 off –
Red Only for emergency
switching off/emer-
gency stop switches
To IEC/EN 60204-1,
VDE 0113 Part 1
T0-…/E, …/IVS, …/Z, …/I1
T3-…/E, …/IVS, …/Z, …/I2
P1-…/E, …/IVS, …/Z, …/I2
KNB-RT-T0
043655
10 off • Order yellow FS908GE-T0
front plate additionally
Black – T5(B)-…/E, …/Z, …/I4
P3-63/E, …/Z, …/I4
P3-100/E, …/Z, …/I5
KNB-P3
041282
10 off –
Red Only for emergency
switching off/emer-
gency stop switches
To IEC/EN 60204-1,
VDE 0113 Part 1
T5(B)-…/E, …/Z, …/I4
P3-63/E, …/Z, …/I4
P3-100/E, …/Z, …/I5
KNB-RT-P3
046028
10 off • Order additional yellow
front plate FS908GE-P3
Maintenance key for interlocked main switches
T0…
P1…
KNK-T0
000650
5 off Special devices for electri-
cians: interlocked main
switches can be switched on
and off for repairs with the
maintenance key while the
door is open (as per IEC/EN
60204-1, Section 5.1.1.1)
P3… KNK-P3
000649
5 off
ATEX type
According to 94/9EG
Test Certificate BVS04E106X
With metric knock-outs M20 T0-…/I1 +ATEX-I1
237513
1 off Only available together with
basic unit
With solid side walls T3-…/I2
P1-…/I2
+ATEX-I2
237514
T5B-…/I4
P3-…/I4
+ATEX-I4
237516
T5-…/I5
P3-…/I5
+ATEX-I5
237517
Information relevant for export to North America
UL/CSA certification not required
SVB-...-T0(P3), KNB-...-T0(P3) HPL04058EN
