4/54 Cam switches, switch-disconnectors
Control switches – Instrument switches
2010 CA08103002Z-EN
www.eaton.comControl switches– Instrument switches
Flush mounting
1)
Center mounting
1)
Contact sequence
Front plate
no.
Pole
Main
contacts
Front IP65
Front IP65
Pole
Part no.
Article no.
Price
See
price
list
Std. pack
Part no.
Article no.
Price
See
price
list
Std. pack
N/O
Voltmeter selector switch
With black thumb-grip and front plate
3 x phase-N with 0 position 3 + N
T0-2-15921/E
067337
1 Off
T0-2-15921/EZ
069710
1 Off
3 x phase-phase
3 x phase-N with 0 position
3 + N
T0-3-8007/E
095813
T0-3-8007/EZ
098186
3 x phase-phase
3 x phase-N without
0 position with complete
rotation in both directions
3 + N
T0-3-15924/E
019878
T0-3-15924/EZ
022251
3 x phase-phase with
0 position
3
T0-2-15920/E
038861
T0-2-15920/EZ
041234
3 x phase-phase without
0 position
3
T0-2-15922/E
053099
T0-2-15922/EZ
055472
Ammeter selector switch
With black thumb-grip and front plate
With complete rotation in both directions.
Measurement via current transformer
With 0 (Off) position
T0-3-8048/E
034116
1 Off
T0-3-8048/EZ
036489
1 Off
Information relevant for export to North America
1)
Product Standards
UL 508; CSA-C22.2 No. 14-05; IEC/EN 60947-3;
CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
12528
CSA Class No.
3211-05
NA Certification
UL Listed, CSA certified
Suitable for
Branch circuits
Degree of Protection
IEC: IP65; UL/CSA Type 3R, 12
1
2
