4/52 Cam switches, switch-disconnectors
Control switches – changeover switches, manual/automatic switches
2010 CA08103002Z-EN
www.eaton.comControl switches–changeoverswitches,manual/automatic switches
Flush mounting
1)
Center mounting
1)
Contact sequence
Front plate no.
Main
contacts
Front IP65
Front IP65
Pole
Part no.
Article no.
Price
See price
list
Std. pack
Part no.
Article no.
Price
See price
list
Std. pack
N/O
Universal control switches
With black thumb-grip and front plate
Maintained switches with 3 positions
1 contact closed in each position
• Additionally 1 contact closed in position 0 and 1
• Additionally 1 contact closed in position 0 and 2
• Additionally 1 contact closed in position 0 and 3
T0-3-15391/E
029365
1 Off
T0-3-15391/EZ
031738
1 Off
Momentary from positions 1 and 2
With black thumb-grip and front plate
T0-3-15394/E
072079
1 Off
T0-3-15394/EZ
074452
1 Off
1
2
3
4
5
6
7
8
9
10
11
12
2 0 1
FS 429
0
2 1
1
2
3
4
5
6
7
8
9
10
11
12
2 0 1
FS 458
0
1 2
Coding switches
With black thumb-grip and front plate
With complete rotation in both directions.
Binary
BCD code
T0-4-15602/E
029368
1 Off
T0-4-15602/EZ
031741
1 Off
1
2
3
4
5
6
7
8
9
10
11
12
13
14
0 1 2 3 4 5 6 7 8 9
15
16
4 2
0
3
9
6
8
1
5
7
FS 312
Series switches
With black thumb-grip and front plate
With 0 (Off) position
(heater switches)
1
T0-1-91/E
072082
1 Off
T0-1-91/EZ
074455
1 Off
Information relevant for export to North America
1)
Product Standards
UL 508; CSA-C22.2 No. 14-05; IEC/EN 60947-3; CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
12528
CSA Class No.
3211-05
NA Certification
UL Listed, CSA certified
Suitable for
Branch circuits
Degree of Protection
IEC: IP65; UL/CSA Type 3R, 12
1
2
3
4
0 1 2
FS 614
0
2 1
T
