4/56 Cam switches, switch-disconnectors
Switches with locking mechanism
2010 CA08103002Z-EN
www.eaton.comSwitcheswith lockingmechanism
Flush mounting
Contact sequence
Front plate no.
Main
contacts
Max. motor
rating
AC-23 A, 400/415
V, 50/60 Hz
Rated
uninter-
rupted
current
IP65
Part no.
Article no.
Price
See
price
list
Std. pack
Pole
400 V
I
u
N/O
P
A
kW
Panic switch
Cylinder lock SVA
Without emergency switching off/emergency stop function, with two keys
With black thumb-grip and front plate
If the key is withdrawn in position 1 the switch can be switched off
but not on again without the key.
3
6.5
20
T0-2-1/E/SVA(S)
050977
1 Off
3
13
25
P1-25/E/SVA(S)
050966
3
15
32
P1-32/E/SVA(S)
044977
As an emergency switching off/emergency stop device
To IEC/EN 60204-1, VDE 0113 Part 1
With two keys
With red thumb-grip and yellow front plate
3
6.5
20
T0-2-1/E/SVA(S)-RT
228291
1 Off
3
13
25
P1-25/E/SVA(S)-RT
050967
3
15
32
P1-32/E/SVA(S)-RT
050971
Padlocking feature SVC
As an emergency switching off/emergency stop device
To IEC/EN 60204-1, VDE 0113 Part 1, with two keys
With red thumb-grip and yellow front plate
If the locking slide is padlocked in position 1 the switch can be switched off but not on again
without removing the padlock.
Lockable with max. 3 padlocks.
3
6.5
20
T0-2-1/E/SVC(S)-RT
044973
1 Off
3
13
25
P1-25/E/SVC(S)-RT
044974
3
15
32
P1-32/E/SVC(S)-RT
044975
On-Off switches
Without emergency switching off/emergency stop function
With black thumb-grip and front plate
Key can only be withdrawn in position 0 (Pos A)
3
6.5
20
T0-2-1/E/SVA(A)
050976
1 Off
3
13
25
P1-25/E/SVA(A)
050965
3
15
32
P1-32/E/SVA(A)
050970
Key operation lock mechanism ST-0
Without emergency switching off/emergency stop function
With black thumb-grip and front plate
Key can only be withdrawn in position 0 (Pos A)
2
6.5
20
T0-1-102/EZ/S
014933
1 Off
1
2
3
4
5
6
0 1
FS 908
ON
OFF
1
2
3
4
5
6
0 1
FS 908 GE
1
0
1
2
3
4
5
6
0 1
FS 908 GE
1
0
1
2
3
4
5
6
0 1
FS 908
ON
OFF
1
2
3
4
0 1
FS 908
ON
OFF
