4/48 Cam switches, switch-disconnectors
Control switches – changeover switches, manual/automatic switches
2010 CA08103002Z-EN
www.eaton.comControl switches–changeoverswitches,manual/automatic switches
Flush mounting
1)
Center mounting
1)
Contact sequence
Front plate no.
Main
contacts
Front IP65
Front IP65
Pole
Part no.
Article no.
Price
See price
list
Std. pack
Part no.
Article no.
Price
See price
list
Std. pack
N/O
Changeover switches
With black thumb-grip and front plate
1
T0-1-15421/E
095806
1 Off
T0-1-15421/EZ
098179
1 Off
2
T0-2-15422/E
019871
T0-2-15422/EZ
022244
3
T0-3-15423/E
034109
T0-3-15423/EZ
036482
1
2
3
4
2 0 1
FS 429
0
2 1
1
2
3
4
5
6
7
8
2 0 1
1
2
3
4
5
6
7
8
9
10
11
12
2 0 1
Manual/Auto switches
With 0 (Off) position
1
T0-1-15431/E
019872
1 Off
T0-1-15431/EZ
022245
1 Off
2
T0-2-15432/E
034110
T0-2-15432/EZ
036483
3
T0-3-15433/E
048348
T0-3-15433/EZ
050721
With momentary from HAND
1
T0-1-15434/E
062586
1 Off
T0-1-15434/EZ
018053
1 Off
2
T0-2-15435/E
003191
1 Off
T0-2-15435/EZ
003192
1 Off
With momentary from START
2
T0-2-15907/E
066931
1 Off
T0-2-15907/EZ
069304
1 Off
Without 0 (Off) position
1
T0-1-15451/E
076824
1 Off
T0-1-15451/EZ
079197
1 Off
2
T0-2-15452/E
091062
T0-2-15452/EZ
093435
3
T0-3-15453/E
015127
T0-3-15453/EZ
017500
Information relevant for export to North America
1)
Product Standards
UL 508; CSA-C22.2 No. 14-05; IEC/EN 60947-3; CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
12528
CSA Class No.
3211-05
NA Certification
UL Listed, CSA certified
Suitable for
Branch circuits
Degree of Protection
IEC: IP65; UL/CSA Type 3R, 12
