Cam switches, switch-disconnectors
Cam switches
2010 CA08103002Z-EN
4/5
Service distribution
board mounting (…/IVS) 1
Front IP30
Can be snapped onto top-
hat rail as per IEC/EN 60715
(only T0 and T3)
Mounting
• In service distribution
board up to 3 contact
units (45 mm mounting
depth)
• In control panel up to
11 contact units
￫Page 4/22
Rear mounting (.../Z) 2
Front IP65
Fixing: optionally with
screw fixing or snap fitting,
only T0 und T3
For snap fitting to
IEC/EN 60715 top-hat rail
Drive coupling in door or
cover
Connection from front
￫Page 4/22
Rear mounting main
switch (...V/SVB) 2
Front IP65
To IEC/EN 60204, VDE 0113
and IEC/EN 60947-3
For T0…: up to 8 contacts;
For T3…: up to 12 contacts
With door interlock in "I"
position
￫Page 4/10
Flush mounting (.../E) 3
Front IP65
Flush mounting and
connection from rear
Terminals:
Crosshead screwdriver
Pozidrive
T8 always with extension
terminals
￫Page 4/22
Flush mounting main
switch (.../EA/SVB) 3
Front IP65
To IEC/EN 60204, VDE 0113
and IEC/EN 60947-3,
For T0…: up to 8 contacts;
For T3…: up to 12 contacts
N and PE terminal
￫Page 4/10
Center mounting (.../EZ) 3
Front IP65
Mounted in ⌀ 22.3 fixing
hole to IEC/EN 60947-5-1
"One man mounting" by
center fixing
￫Page 4/22
Surface mounting (.../I...) 4
IP65
With an additional terminal
Enclosures for metric cable
glands to EN 50262
￫Page 4/22
Surface mounting main
switch (.../I...) 4
IP65
To IEC/EN 60204, VDE 0113
and IEC/EN 60947-3,
For T0…: up to 8 contacts;
For T3…: up to 10 contacts
Position 0 lockable with
3 padlocks
Enclosures for metric cable
glands to EN 50262
With an additional terminal
￫Page 4/10
￫Page 4/58
Safety switch (.../I...) 5
IP65
With an additional terminal
With cover fixing in
0 position
Position 0 lockable with
3 padlocks
Enclosures for metric cable
glands to EN 50262
"Safety Switch" label; color:
orange
￫Page 4/30
￫Page 4/58
ATEX
ATEX
Main switch (kit) for use
as emergency switching
off device
6
To IEC/EN 60204-
1,VDE 0113 part 1
With red rotary handle and
yellow locking collar
Lockable in the 0 (Off)
position
￫Page 4/58
Main switch (kit) 7
Black rotary handle and
locking collar
Lockable in the 0 position
￫Page 4/58
Thumb-grip, for use as
emergency switching off
device
8
To IEC/EN 60204-1,
VDE 0113 part 1
Red thumb-grip and yellow
front plate
￫Page 4/58
Thumb-grip 9
Black thumb-grip with front
plate
￫Page 4/58
Coupling drive 10
Including push-fit shaft
For the retrofitting of switch
T0(T3)‐.../XZ as rear
mounting, spare part for
T0(T3)/(P1)‐.../Z
For the conversion of
T5(B)‐.../E flush mounting
switch to rear mounting,
spare part for T5(B)/(P3)‐...Z
￫Page 4/65
Note:
Cam switches T5
and T5B are only available
with screw connections for
fixing on a mounting plate.
T
