3/92 Sensors
Comet series
2010 CA08103002Z-EN
Optical sensors
Optical sensorsCometseriesTechnical data
3-wire
111 Types 121 Types 131 Types 141 Types
General
Standards IEC/EN 60947-5-2
Ambient temperature °C -20 - +70 -40 - +70 -40 - +70 -40 - +70
Protection type IP67 IP67 IP67 IP67
Mechanical shock resistance g 100
Shock duration 3 ms
Characteristic values
Rated operating voltage 20 - 264 V AC
15 - 30 V DC
20 - 264 V AC
15 - 30 V DC
20 - 264 V AC
15 - 30 V DC
20 - 264 V AC
15 - 30 V DC
Operating current in the
switched state at 24 V DC
I b mA 25 30 30 30
Rated operational current I e mA 300 300 300 300
Switching frequency Hz – 50 50 50
Switching state indication LED – Red Red Red
Operating voltage indication LED Red – – –
Protective functions Short-circuit protection
Protection against polarity reversal
Protection against wire breakage
Function 3-wire 3-wire 3-wire 3-wire
Construction type
Design (outer dimensions) M18 x 1 M18 x 1 M18 x 1 M18 x 1
Connection options Cable open
2 m connection cable
Material plastic
4-wire
111 Types 121 Types 131 Types 141 Types
General
Standards IEC/EN 60947-5-2
Ambient temperature °C -20 - +70 -40 - +70 -40 - +70 -40 - +70
Protection type IP67 IP67 IP67 IP67
Mechanical shock resistance g 100
Shock duration 3 ms
Characteristic values
Rated operating voltage 10 - 30 V DC 10 - 30 V DC 10 - 30 V DC 10 - 30 V DC
Operating current in the
switched state at 24 V DC
I b mA 25 30 30 30
Rated operational current I e mA 100 100 100 100
Switching frequency Hz – 142 500 500
Switching state indication LED – Red Red Red
Operating voltage indication LED Red – – –
Protective functions Short-circuit protection
Protection against polarity reversal
Protection against wire breakage
Function 4-wire 4-wire 4-wire 4-wire
Construction type
Design (outer dimensions) M18 x 1 M18 x 1 M18 x 1 M18 x 1
Connection options Cable open
2 m connection cable
Material plastic
Notes Further technical data can be found in the Online Catalogue at
