22/18 Switchgear for North America
Degrees of protection of enclosures to NEC (NFPA 70), UL, CSA, NEMA
2010 CA08103002Z-EN
Enclosure
Enclosure and protection type marking to
Location Type of protection Comparable
degree of
protection IP3)
NEC NFPA 70 1)
NEMA No. 250–1997, Appendix A2)
UL 50
CSA-C 22.2 No. 94
Type 1
General purpose
Indoor installation Protection against accidental contact with live parts and against
a limited amount of falling dirt.
IP20
Type 2
Drip-proof Indoor installation Protection against limited amounts of falling water and dirt IP22
Type 3
Dust-tight, rain-tight, resistant to sleet and ice
Outdoor installation Protection against wind-blown dust and wind-blown rain.
Undamaged by formation of ice on the enclosure
IP54
Type 3R
Rain-tight, resistant to hail and ice, dust-tight Outdoor installation Protection against falling rain; undamaged by formation of ice on the
enclosure IP54
Type 3S
Dust-tight, rain-tight, resistant to sleet and ice
Outdoor installation Protection against hail wind-blown dust and wind-blown rain.
External mechanisms remain operable while ice laden.
IP54
Type 4
Dust-tight, water-tight, rain-tight Indoor or outdoor instal-
lation Protection against falling rain, splashing water and hosed water.
Undamaged by formation of ice on the enclosure IP56
Type 4X
Dust-tight, water-tight,corrosion-resistant,
rain-tight
Indoor or outdoor instal-
lation
Protection against falling rain, splashing water and hosed water.
Undamaged by formation of ice on the enclosure, corrosion
protection
IP56
Type 6
Rain-tight, water-tight, immersible,
resistant to hail and ice
Indoor or outdoor instal-
lation
Protection against dust and hosed water.
Protection against entry of water during temporary limited submersion.
Undamaged by formation of ice on the enclosure.
IP67
Type 6P
Rain-tight, water-tight, immersible,
corrosion-resistant
Indoor or outdoor instal-
lation Protection against entry of water during prolonged submersion
at limited depths; corrosion-resistant. IP67
Type 5
Drip-tight, dust-tight, corrosion-resistant
Indoor installation Protection against limited amounts of falling water and dust,
corrosion-resistant.
IP52
Type 12
For use in industry, drip-tight, dust-tight
Indoor installation Protection against dust and dripping water IP52
Type 12K4)
As type 12
Indoor installation As part no. 12 IP52
Type 13
Dust-tight, oil-tight
Indoor installation Protection against entry of dust, splashing water, oil and
non-corrosive fluids.
IP54
Notes 1) NEC = National Electrical Code
2) NEMA = National Electrical Manufacturers Association
3) The IP rating provided as an approximate comparison. A more accurate comparison is not possible, since different
ingress protection tests and assessment criteria apply.
The NEMA types cover the corresponding IP ratings but not the other way round. In general, NEMA/UL enclosure
protection testing is subject to stricter criteria.
4) For enclosures with knockouts.
