22/16 Switchgear for North America
Switching duty of auxiliary contacts, rating data for three-phase contactors to NEMA
2010 CA08103002Z-EN
Code number 1) Conventional
free air thermal
current
I th
Maximum switching duty
120 V AC 240 V AC 480 V AC 600 V AC 600 V AC
A
ON
A
Off
A
ON
A
Off
A
ON
A
Off
A
ON
A
Off
A
ON
VA
Off
VA
Auxiliary contacts
in AC control circuits
Heavy
pilot
duty2)
A 150 10 60 6 – – – – – – 7200 720
A 300 10 60 6 30 3 – – – – 7200 720
A 600 10 60 6 30 3 15 1.5 12 1.2 7200 720
Standard
pilot
duty3)
B 150 5 30 3 – – – – – – 3600 360
B 300 5 30 3 15 1.5 – – – – 3600 360
B 600 5 30 3 15 1.5 7.5 0.75 6 0.6 3600 360
E150 0.5 1.8 0.3 – – – – – – 216 36
Code number 1) Conventional
free air thermal
current
I th
Maximum switching duty
125 V DC
On/Off 250 V DC
On/Off 310 600 V DC
On/Off 600 V DC
On/Off
A A A A VA
Auxiliary contacts
in DC circuits
Heavy
pilot
duty2)
N 150 10 2.2 – – 275
N 300 10 2.2 1.1 – 275
N 600 10 2.2 1.1 0.4 275
Standard
pilot
duty3)
P 150 1.1 – – 138 –
P 300 5 1.1 0.55 – 138
P 600 5 1.1 0.55 0.2 138
– Q 150 2.5 0.55 – – 69
Q 300 2.5 0.55 0.27 – 69
Q 600 2.5 0.55 0.27 0.1 69
– R 150 1 0.22 – – 28
R 300 1 0.22 0.11 – 28
Notes 1) The values 150, 300 and 600 indicate die maximum voltage for which an auxiliary contact can be used.
2) “Heavy Pilot Duty“ = High switching duty
3) “Standard Pilot Duty” = normal switching duty
4) Rating data for 3-phase contactors, for single-speed motors, without inching, reversing or regenerative braking.
