Switchgear for North America

protective devices. Overload protec-

tion of a single, directly connected

motor can be provided directly by the

frequency. For drives with several

motors and bypass circuits the motors

must be individually overload-

protected with overload relays.

The frequency inverters are used in

branch circuits. They can be used with

three-phase rated operating voltages

of up to 480Y/277 V, 50/60 Hz. Because

of their suppressor circuit, solidly

grounded star networks with neutral

conductor are always required.

Radio interference suppression

measures (EMC) in frequency-

controlled power drive systems (PDS)

are not specified in the North Amer-

ican standards. To ensure interfer-

ence-free operation, the EMC

measures laid out in IEC/EN 81600-3

should be carried out for machines

and plants for export to North America.

Control relays easyRelay

and MFD silver

Electronic control relays easyRelay

and multi-function displays MFD-Titan

have all UL 508 and CSA-C22.2 No.142

approvals. They are also approved

to CSA (Class 1, Div. 2) for use in

hazardous locations to CSA-C22.2

No. 213-M1987(R2008)

1)

.

All technical details for the North

American market in this catalog, in the

installation instructions and in the

manuals are also given in American

units, such as inches, lb, and degrees

Fahrenheit. The relay data are given in

pilot duties B300, R300, and

make/break. The operational DC

voltage of 24 V is also the common

voltage for electronic components and

systems in North America.

easyRelay and MFD-Titan are

programmed in programming

language ladder diagram. The

easySoft software is also capable of

representing North American ANSI

contact sequences.

Control relays easyRelay and multi-

function displays MFD-Titan are

therefore fully equipped as control

components/systems for the North

American market.

Protection types for enclosures

(

degree of protection)

The binding design and degree of

protection requirements for enclo-

sures for the USA are defined in

NEC = NFPA 70, in UL 508(A) and in

UL 50(E). For Canada they are

specified in CSA-22.2 No. 14-05

and in CSA-C 22.2 No. 94. The

degrees of protection are given as

NEMA types or as identical

UL/CSA types. Because the

UL/CSA types must be third-party

certified, they have largely super-

ceded the NEMA types. Many

inspectors demand UL/CSA types.

Where products with third-party

certified UL/CSA types are avail-

able, they should be used in prefer-

ence.

The enclosures used by Eaton are

accepted for use in North America,

since they are approved with

UL/CSA types and meet the

requirements regarding contact

protection, corrosion protection

and ingress protection against

solids and liquids. See the informa-

tion about degree of protection on

the selection pages or in the tech-

nical specifications for the product

groups.

The IEC/EN standard ingress

protection (IP) types include

protection against ingress of solids

and water. The comparable stan-

dards in Canada and the USA go

further, also covering protection

against ingress of oil and coolant,

and corrosion protection of the

enclosure; they therefore also

define its place of installation. The

table on a Page 22/xx ((17/18))

provides an overview of the

requirements in Canada and the

USA and a comparison with the

IP ratings.

IP protection type information has

no relevance for use in North

America and can not replace

missing information about

NEMA/UL/CSA types. The

NEMA/UL/CSA types cover the

corresponding IP ratings but not

the other way round.

When exporting to North America,

particular attention must be paid to the

selection and implementation of the

correct degree of protection for

enclosures and installed apparatus.

The inspectors are known to check

very thoroughly for adherence to the

degrees of protection. In almost every

case, plants fail the inspection on this

aspect and must be rectified. This

results in lost time and additional

costs. Always choose enclosures with

the right degree of protection from the

start. Every opening subsequently

made in an enclosure puts its degree

of protection into question. The degree

of protection remains intact only when

each of these enclosures is sealed

again to the same degree. This can be

done, for example, by installing a

control circuit device or switch handle

with the same or a higher degree of

protection. Likewise, all openings that

are not immediately apparent because

they are hidden by other components

must be sealed. In most cases the

assembly personnel knows exactly

where work was performed with less

than 100 percent accuracy. Hoping

that this will not be noticed will usually

result in severe problems. To obtain

acceptance, these locations will later

have to be improved at great cost.

Improvements carried out at the

customer’s site are specially expen-

sive. Here, too, it should be remem-

bered that this work has to often be

performed by a North American

vendor and can not be carried out by

the manufacturer, who can then, at

best, take on the role of supervisor.

Sheet-steel enclosures and

installation technique

Sheet steel enclosures can be used for

all types of controllers. In North

America, and specially in power distri-

bution systems cables are commonly

laid in metal conduits. Into these

conduits, individual strands, not whole

cables, are laid. The conduits are

bolted together along their entire

length to act as continuous grounding

conductor. They are connected to the

enclosure flanges with suitable metal

glands. Enclosures with metal flanges

ensure an uninterrupted conducting

connection between incoming and

outgoing conduits, so that the enclo-

sures are included in the grounding

measure. Sheet steel enclosures with

metal or insulating flanges are also

suitable for connecting plastic

conduits and cables, which are

connected with commercial glands.

In this configuration, protective

grounding must be provided with a

ground conductor routed with the

cabling. This cable routing type has

established itself in many modern

installations and is today the preferred

choice, for example for machines. On

machines, only the input wiring to the

main switch is often installed with

metal conduits. Regarding the configu-

ration and space utilization of cable

trays, cable ducts and wiring ducts in

control panels, the limitations imposed

by the Electrical Codes must be

observed. The permissible space

utilization lies some way below that

usually specified by the IEC/EN stan-

dards. Inspectors usually investigate

this aspect in great detail. Where

cable trays and ducts are secured to

the building, extensive regulations of

the Electrical Codes must be observed.

Consistent grounding of all compo-

nents that must be included in the

grounding system will be thoroughly

inspected and objections are not

infrequent. The required grounding

conductor cross-sections must be

adhered to under all circumstances.

Another important aspect is the

protection of the insulation of

electrical cables where the cables are

routed through openings or are

exposed to movement during machine

operation (for example trailing cables).

Cables that are mechanically

protected in IEC/EN installations must,

of course, also be protected in plants

destined for export to North America.

The cables as well as all materials

used for routing and securing them

must be verifiably approved. Always

observe the installation and dimen-

sioning instructions of the Electrical

Codes.

Wall-mounting enclosures CS

Eaton now supplies a new enclosure

systemwith approvals for the USA and

Canada. Wall-mounted enclosures

in 45 enclosure sizes ranging from

250

× 200 × 150 mm (h × w × d) to

1200

× 800 × 300 mm are available. The

smaller enclosures are ideal for

enclosing individual devices or small

combinations, such as motor-starter

combinations or frequency inverters

complete with the additionally

required components. The larger

enclosures are suitable for

constructing small to medium-sized

machine controllers. It is advisable,

wherever possible to fix the enclo-

sures to the machine. This has the

added advantage that the machine

can be delivered ready for connection

and fully function-tested. If the enclo-

sures and installation are mounted on

the building, the extensive installation

regulations of the Electrical Codes

must be observed. The enclosures

have a high degree of protection

(

IP65 UL/CSA Types 1 and 12, indoor

use only). The surrounding rain

channel profile offers protection

against the ingress of liquid such as

water or oil as well as dirt when the

door is opened. A powder-coated

textured surface provides abrasion-

resistant corrosion protection. The

enclosures feature galvanized sheet

steel mounting plates. Sheet steel

bottom plates for self-assembly are

available. The enclosure can be turned

through 180° for cable entry from

above or below.

Insulated enclosures CI-...-NA

Enclosures CI-…-NA fulfil the statu-

tory North American requirements for

the construction and degree of protec-

tion, which is laid out in UL 508(A) for

the USA and in CSA-C22.2 No. 14-05 for

Canada. They are therefore suitable

for enclosing motor starters and

miniature and small controllers for

installations and machinery. With their

complete corrosion-resistance they

are ideally suited for humid or corro-

sive environments. The enclosures are

suitable for the connection of cables

and both metal and plastic conduits,

which are connected with commercial

screwed glands. Because the “total

insulation” that Eaton offers for its

enclosures is not recognized for

insulating enclosures in the USA and

Canada, the enclosures must be

grounded according to the enclosed

installation instructions.

Enclosures CI-...-NA are approved

both with and without insulated

flanges. For the full range of CI

enclosures with UL/CSA approvals

see Chapter 20.

Busbar systems SASY60i

Busbar systems are an essential part

of IEC/EN installations and of modern

control systems. In North America

they are still relatively new. There,

power distribution to switching and

protective devices is frequently still

implemented using power distribution

blocks, which are less well known in

the rest of the world. In 2007, when

Moeller began to introduce the busbar

system SASY 60i, the system’s compo-

nents received only approvals as UL

Recognized Components and CSA

Certified Components. In the mean-

time, most of the system’s key compo-

nents are approved as UL Listed and

CSA Certified Components – see the

markings on the selection pages. This

was an important step, as Listed

Components no longer have to be

included at additional cost into the

certification reports for switchgear

systems. In the next edition of UL 508A

the busbar system are expected to

also be included in “Component

Requirements” SA1, Table SA1.1.

Initially, the busbars were approved

only for peak loads of 1000 A/inch² or

1.55

A/cm², which is about half of the

load capability according to IEC/EN. In

the meantime, the busbars have been

tested and approved with IEC/EN

loads. This was a major step for

machine and panel builders that want

to supply world-market machines and

control panels.

Notes

1)

Non-Incendive Electrical Equipment for Use in Class I, Division 2 Hazardous

Locations]
