Eaton Main Catalogue for Industry
Highlights
Practically all devices can be used in compliance with IEC
norms.
The selection pages of this catalogue indicate the products that
have been approved for the North American market with the USA
and Canadian flags. This does not mean these devices are exclu-
sively for North America! Approval for North America has been
granted special emphasis due to the strong export share of these
devices and because standards deviate from IEC/EN norms, selec-
tion and and processing requirements must be highlighted. The arti-
cle "Switchgear for North America" in the appendix of this catalogue
contains everything you need to know about this subject.
A glossary in the appendix explains the specifically American techni-
cal terms.
Eaton Sensors
The Eaton sensors significantly extend the previous Moeller spectrum
of position switches and sensors.
The familiar position switches of the series LS-Titan have been supplemen-
ted by a great number of electrical sensors: inductive, optical and capacitive.
The basic devices have been supplemented and completed by a com-
prehensive scope of accessories for mounting aids, cables and multi-
sensor connection blocks.
Switchgear for the global market and for North America:
E65 SM:
The TargetLockTM technology
stands for the simplest setting
work. Optimal performance in a
smaller construction type.
Example for such an instruction.
The Std. pack column on the order pages also uses flags to indicate the
articles for which the UL/CSA notes apply.
Selecting a technically appropriate device also opens information to
help you document suitability for use in North America on your own
with a minimum of research (see above).
Information relevant for export to North America
Product Standards
IEC/EN 60947-5;
UL 508, CSA-C22.2 No. 14;
CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
12528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA Certified
Degree of Protection IEC: IP65, UL/CSAType 3R,
4
X (indoor use only), 12, 13
Eaton Sensors in this catalogue:
Chap. 3 –
Position switches, sensors,
pressure switches
GLOBAL series E57:
Inductive sensors in standard
industrial design.
PREMIUM plus series:
Inductive sensors in miniature
design. Include greater clearances,
longer lifespans.
iProx series:
The programmable inductive sen-
sor permits variable setting of swit-
ching interval and functionality as
well as shielding from background
metals.
Series E52 and E56:
Inductive proximity switch. High
performance and durability in
industrial standard enclosures.
￫Page 3/xx
Comet series:
Optoelectronic sensors with integ-
rated one-way or reflection light
barriers, with/without background
suppression, optional connection
of fibre optic cables.
E58 Harsh Duty:
For use in harsh environments,
where high pressure or steam jets
etc. are used.
