Highlights
SmartWire Darwin products in this catalogue:
Chap. 1 – SmartWire Darwin- the complete
range
Chap. 2 – Pilot devices
Chap. 5 – Contactors
Chap. 7 – Motor protective circuit breaker
Chap. 9 – Softstarter
Chap. 17 – Compact circuit-breakers
SmartWire Darwin reduces cabling effort on many switchgear systems by over 60 percent
and helps save costs along the entire work chain – from design through construction and
commissioning, up to expansion. Here, SmartWire-DT relies on proven Moeller industrial
switchgear devices and enables them to communicate.
Planning and
engineering efficiently
Convenient
operation
Fast commissioning
Easy expansion
Connecting error-free
Maintenance with
direct diagnostics
SmartWire-Darwin Communication System
Evolution in the control panel
For the manufacturer of machinery and installations,
finding the optimal balance between maximum func-
tionality and optimal costs is paramount. Designed
for further development, SmartWire Darwin is a
communication system for industrial switchgear in
control panels and the periphery: from control,
protection and switching to actuation, operation and
monitoring.
One technology from which you will profit, now and
in the future.
xBoard enclosure and energy distribution program
Utilised in industry and buildings – enclosures from Eaton are convincing.
High flexibility, easily adapted to frequently changing circumstances.
Designed for long-term mechanical loads.
High mechanical stability.
Numerous enclosure variants.
Time-saving mounting units.
Prefabricated energy and control distributions.
Our system partner switchgear systems operate prefabricated energy
and control distributions worldwide.
Combination enclosure XVTL
55 sizes to select from.
Height: 1400–2000mm,
width: 425–1200mm
depth: 300–800mm.
Robust type, in commercial
buildings as well as in industry.
Chap. 22
Service distribution board IVS
A wide variety of mounting units,
tailored to original Eaton switch-
gears and protection devices.
Time-saving, easy mounting.
Chap. 22
Busbar system SASY 60i
Utilized in control panels in machi-
nery and installations worldwide.
Large air and creepage distances
according to UL508A.
Especially suitable for CI insulated
enclosures (Chap. 20), CS steel
enclosures (Chap. 21) and combi-
nation enclosures (Chap. 22).
Chap. 16
CS sheet steel wall-mounting enclosure
45 enclosure sizes: 250 x 200 x 150 mm –
1200 x 1200 x 250 mm.
Effective protection against direct contact with live
parts. Full safety and protection from damaging
ambient conditions through protection type IP66.
Ideal for inclusion of SmartWire Darwin components.
Chap. 21
CI insulated enclosures
Flexible in assembly: individual
enclosures, wall-mounting dis-
tribution systems, floor standing
distribution boards in many sizes –
always the right solution.
Ideal for the circuit-breaker NZM
(Chap. 17) and the photovoltaic com-
ponents (cf. alongside) from Eaton.
Chap. 20
