6 / 12
CSBC 18MBP1
18
BB1 Blanking
Strip
16
CL
MCBLD + 748
17
CC
(
fitted to Earth Bar)
CLEB12 CLNB12
INDIVIDUAL ENCLOSURES
l
H W D Insulated
2
Modules wide 152 63 63
18
GP2S
4
Modules wide 152 79 61
18
GP4S
H W D Metalclad
2
Modules wide 225 90 67
18
GP2M
4
Modules wide 317 136 82
18
GP4M
GENERAL LOADSTAR ACCESSORIES TP & SP
l
List No
Cylinder Lock & Key
16
CL
MCB Locking device (excl. lock)
MCBLD
Padlock & Key for use with MCBLD
748
Clean Earth Bar Kit ‘L’ & ‘H’ Boards only.
18
CEBK
(4
to 12 way=1 kit, 16 to 24 way=2 kits).
Blanking Strip - 6 Individual 1 module wide pieces
18
BP1/6
Blanking Strip - 12 Individual 1 module wide pieces
18
BP1/12
Blanking Strip - 4 lengths each 3 modules wide
18
PB3/4
Blanking Strip - 2 lengths each 12 modules wide
18
BP12/2
Clip In Blank SP Moulding
CSBC
Busbar cross connector insulator - pack of 9
18
BB1
SP MCB size Blank (shields MCB & Busbar Terminal)
18
MBP1
Cable clamp assembly (70mm
2
) -
pack of 3
17
CC
l
Previously manufactured DBs utilize 18CB1 blank pieces
ADDITIONAL EARTH BAR KITS
l
Additional Earth Bars to fit TP Distribution Boards
No of Ways List No No of Ways List No
4
18
EB04
16
18
EB16
6
18
EB06
20
18
EB20
8
18
EB08
24
18
EB24
12
18
EB12
Earth and Neutral bar, 10mm
2
cable max, for use with DIN Rail
NEUTRAL EARTH
7
Terminals
CLNB07 CLEB07
12
Terminals
CLNB12 CLEB12
15
Terminals
CLNB15 CLEB15
18
AS2
18
DIN18
DINRAIL, ROWBOARD, SERVICE CENTRES
l
Rowboard:
l
Suitable for ’Stand-Alone‘ use or ’Add-On‘ above surface ’L‘ type board.
l
Each row will accommodate 18 off 18mm module wide DIN Rail mounted
devices.
l
Main Neutral and Earth Bars included, along with provision for additional
’
Mini‘ Neutral and Earth bars.
No of Rows H W D Surface
1 245 430 155
18
AS1
2 410 430 155
18
AS2
3 570 430 155
18
AS3
4 735 430 155
18
AS4
5 815 430 155
18
AS5
Service Centre/DIN Rail Board:
l
‘
Add-On’ for fixture above or below surface ’L‘ Type board.
l
Equipped with easily removed DIN Rail to accommodate 18 or 36, 18mm
module wide DIN Rail mounted devices
l
245
mm & 410mm high
18
Module
18
DIN18
36
Module (2 Rows of 18)
18
DIN36
Cable Spreader Box
Add on Enclosure, 245mm high, Blank front cover plate
18
SB
18
GP2S
18
GP4M
