4 / 12
18
LS08MR
18
LS08D
18
SN14
LOADSTAR 125A ‘METER READY’ TYPE B
DISTRIBUTION BOARD
l
No of Ways
H
W
D List No.
4
490 430 155
18
LS04MR
6
570 430 155
18
LS06MR
8
650 430 155
18
LS08MR
12
815 430 155
18
LS12MR
16
895 430 155
18
LS16MR
20
1000 430 155
18
LS20MR
24
1140 430 155
18
LS24MR
l
Integral Metering option
ADD - ON 12W LOADSTAR ‘L‘ BOARD
l
No of Ways
H
W
D List No.
412
675 430 155
18
LS12A
Vertical connection kit
18
LK12V
l
18
LS12A ‘Add-on’ Board is designed to fit above 16, 20 &24 way ‘L‘ Boards,
to create 28, 32 & 36 way TP Boards
l
18
LK12V kit connects 18LS12A to 16, 20 & 24 way Boards
LOADSTAR 125A ‘STANDARD’ TYPE B FLUSH
DISTRIBUTION BOARDS
l
No of Ways
H
W
D List No.
4
540 480 155
18
LF04
6
620 480 155
18
LF06
8
700 480 155
18
LF08
12
865 480 155
18
LF12
16
945 480 155
18
LF16
20
1025 480 155
18
LF20
24
1190 480 155
18
LF24
LOADSTAR 125A ‘STANDARD’ TYPE B
DISTRIBUTION BOARD WITH INTEGRAL DIN RAIL
l
No of Ways
H
W
D List No.
4
650 430 155
18
LS04D
8
815 430 155
18
LS08D
12
975 430 155
18
LS12D
16
1140 430 155
18
LS16D
20
1140 430 155
18
LS20D
l
DIN rail to accommodate up to 18 modules of control devices
Contactor, Timer etc.
l
DIN rail easily removed to assist cabling
l
All devices - Incomer, MCBs & Control equipment - behind common front
plate and outer door
LOADSTAR 125A ‘IP66’ TYPE B DISTRIBUTION
BOARD
l
No of Ways
H
W
D List No.
4
800 500 215
IP18LS04
6
800 500 215
IP18LS06
8
800 500 215
IP18LS08
12
1000 500 215
IP18LS12
16
1000 500 215
IP18LS16
l
Boards consist of IP66 steel enclosure, door, Board interior, Incomer, kit
and MCB extra as for ‘L‘ Boards above
LOADSTAR 125A TYPE A DISTRIBUTION BOARD
l
No of Ways
H
W
D List No.
5
235 188 128
18
SN05
8
235 242 128
18
SN08
11
235 293 128
18
SN11
14
235 343 128
18
SN14
19
235 437 128
18
SN19
l
Board supplied with 125A DP Switch Disconnector
MCBs to be specified and ordered separately
