LOADSTAR 125A TYPE B DISTRIBUTION BOARDS
LOADSTAR 125A INCOMER OPTIONS
LOADSTAR 125A INCOMING OPTIONS
l
Order Device and Kit (where required) separately.
Switch Disconnector, modular (50mm
2
)
Device Kit
40
A TP
40
SW3
63
A TP
63
SW3
None
100
A TP
100
SW3
Required
125
A TP
125
SW3
40
A 4P
40
SW4 18LK125
63
A 4P
63
SW4 18LK125
100
A 4P
100
SW4 18LK125
125
A 4P
125
SW4 18LK125
100
A DP (TP to SP conversion)
100
SW2 18LKTPSP
125
A DP (TP to SP conversion)
125
SW2 18LKTPSP
RCCB (35mm
2
)
Device Kit
40
A 4P 30mA
18
R40/30/4 18LK125
100
mA
18
R40/100/4 18LK125
300
mA
18
R40/300/4 18LK125
63
A 4P 30mA
18
R63/30/4 18LK125
100
mA
18
R63/100/4 18LK125
300
mA
18
R63/300/4 18LK125
100
A 4P 30mA
18
R100/30/4 18LK125
100
mA
18
R100/100/4 18LK125
300
mA
18
R100/300/4 18LK125
100
A 4P 100mA Time Delay
241/100
TD 18LK125
100
A DP 30mA
18
R100/30/2 18LKTPSP
100
A DP 100mA
18
R100/100/2 18LKTPSP
100
A DP 100mA Time Delay
18
R100/100/2TD 18LKTPSP
Special oversize Incoming Cable connection kit
for use with TP Sw Disc above.
Accommodate up to 120mm
2
TP Sw Disc only.
18
LKD120
Direct Connection Device Kit
Incoming Cable Connection (50mm
2
)
18
LKD50
Outgoing Cable Connection Kit/Shroud
None
(50
mm
2
) (
Set of 3 Cable Clamps + Shroud)
18
LKD70
Required
l
Incoming options -
order separately
:
125
A Switch Disconnector TP/4P - 50mm
2
100
A RCCB 4P - 35mm
2
125
A Direct Cable - 50mm
2
l
Integral metering available with Meter Ready
(
MR) board utilising a TP Incoming option
l
Busbars rated at 200A
l
Full compliment of Neutral & Earth terminals
Incoming maximum 70mm
2
Outgoing maximum 25mm
2
l
Allows the fixture of dual Earth bars
l
Clean Earth kit available
l
All boards supplied as standard with hinged
outer door and catch (lock is optional extra)
and removable top/bottom gland plates
l
Neutral busbar supports incorporate an integral
MCB end stop
l
BS EN 60439-3
