Qwikline ll - dual incomer andmulti tariff technical data
Insulated units
Reference number
Cir A
Cir B
Height
Width
Depth
Dual incomer
SQO204
2
4
240
296
127
SQO303
3
3
240
296
127
SQO402
4
2
240
296
127
SQO406
4
6
240
368
127
SQO505
5
5
240
368
127
SQO604
6
4
240
368
127
SQO703
7
3
240
368
127
SQO707
7
7
240
440
127
Metal units
Reference number
Cir A Cir B Cir C
Height
Width
Depth
Dual incomer
SQOM406
4
6
–
247
378
111
SQOM505
5
5
–
247
378
111
SQOM604
6
4
–
247
378
111
SQOM707
7
7
–
247
450
111
Multi tariff
SQOM60501
6
5
1
247
450
111
SQOM70401
7
4
1
247
450
111
Note:
Incoming and outgoing devices must be selected separately from the Qwikline ll devices section.
One incoming device is required per circuit.
Dimensions (mm)
Dimensions (mm)
No. of ways
No. of ways
Incoming
Switch disconnector – 100A
Terminal block
– 100A
RCCB’s
– 63 or 100A/30mA,
100 or 300mA
Control Devices
May be installed at any
outgoing position
Outgoing
MCB’s – B or C curve, 3 - 50A, 6kA
RCBO’s – B curve 6 - 45A, 6kA
Technical data
Metal
Insulated
Max. busbar current rating (A)
100
100
Max. operating voltage (V)
240
240
Operating frequency (Hz)
50
50
Max. incoming cable capacity mm
2
(phase and neutral)
50
50
Max. outgoing cable capacity mm
2
25
25
Certification
BS EN 61439-3
BS EN 61439-3
IP rating BS EN 60529 (internal)
2XB
2XB
