Conduit Take-off Plate
Ref. TRCB20 (20mm)
Ref. TRCB25 (25mm)
Outside Riser
Ref. KLHR 600ER
Standard radius: 300mm.
600 will be supplied formed 90
degrees
Standard radius: 300mm.
600 will be supplied formed 90
degrees
Inside Riser
Ref. KLHR 600IR
600
300 X
Size
Variable Riser
(Fitting widths W. Sizes in mm)
Standard radius: 300mm.
Ref.
Tray Width
mm
50
75
100
150
225
300
450
KLHR50VR
KLHR75VR
KLHR100VR
KLHR150VR
KLHR225VR
KLHR300VR
KLHR450VR
600
350 X
Size
Adjustable Tray Extension
Ref. KLHRATE
Size
50
75
100
150
225
300
450
600
Made to order. Other lengths available on
request.
Adjustable length ranges
300 - 450 500 - 800 750 - 1200
300 - 450 500 - 800 750 - 1200
300 - 450 500 - 800 750 - 1200
300 - 450 500 - 800 750 - 1200
300 - 450 500 - 800 750 - 1200
300 - 450 500 - 800 750 - 1200
300 - 450 500 - 800 750 - 1200
300 - 450 500 - 800 750 - 1200
Adjustable Range
X
X
X
X
HEAVY DUTY CABLE TRAY SYSTEMS
Product Finishing Key (See page 24)
PAUK PATENTED: UK Patent number: GB2476569, IRELAND PATENT PENDING: application number:2010/0795
