The Big Unitrunk Product Guide V4

61 / 162

Reducer
Ref. KLHR/SR
Assembly space = 250mm.
Please state sizes required.
Flat 90° Bend
Ref. KLHR 50-600FB90
50 75 100 150 225 300 450 600
X
Y
Z
R
Size
Flat 45° Bend
Ref. KLHR 50-600FB45
50 75 100 150 225 300 450 600
88 106 124 159 212 283 389 495
72 97 122 172 247 329 479 629
58 58 58 58 58 77 77 77
75 75 75 75 75 100 100 100
X
Y
Z
R
Size
Flat Equal Tee
Ref. KLHR 50-600ET
50 75 100 150 225 300 450 600
196 221 246 296 371 446 596 746
123 148 173 223 298 373 523 673
106 106 106 106 106 106 106 106
75 75 75 75 75 75 75 75
X
Y
Z
R
Size
Flat 4 Way Equal Intersection
Ref. KLHR 50-600FW
50 75 100 150 225 300 450 600
200 225 250 300 375 450 600 750
106 106 106 106 106 106 106 106
75 75 75 75 75 75 75 75
X
Z
R
Size
R: Radius
R: Radius
125 150 175 225 300 400 550 700
213 238 263 313 388 488 638 788
106 106 106 106 106 142 142 142
75 75 75 75 75 100 100 100
R: Radius
R: Radius
250
SIZE
Z
Y
X
X
Z
X
Z
X
Y
SIZE
SIZE
X
SIZE
Z
SIZE
Y
