HEIGHT ADJUSTABLE
COUPLING (18mm MAX)
376mm (for EWTG 3)
432mm (for EWTG43)
1 Lift off 300mm length of lid
2 Take out 300mm length of high-level divider
3 Fit service outlet box
4 Fit outlet panels as required
5 Fit metal lid with polypropylene carpet trim
6 Supplied in 2.4m lengths
UNITRUNK EASY-WAY FLUSH FLOOR TRUNKING
- Is supplied In two standard widths 310mm wide or 366mm wide. Each 2.4M
length comes with four lids to accommodate service outlets. Turnbuckle lid fixings and removable dividers give the end user
great flexibility when positioning services.
UNITRUNK EASY-WAY SERVICE OUTLET
- Is installed in the trunking length, functioning as the support housing adapter for
either service outlet lids or Inspection lids.
UNITRUNK FLOOR SYSTEM OUTLET LIDS
- Accessed from finished floor. These lids can be compatible across all
floor systems trunking supplied as either service or inspection. Lids are supplied in two widths which should be ordered to
match your application.
UNITRUNK SEVICE OUTLET PLATES
- The vast range of service outlet plate acts as housing within the trunking
for electrical components. They can be compatible across all floor systems trunking, when ordering ensure the outlet
plates match your application. (SEE PAGE 124-126 FOR OUTLET PLATES)
Service Outlet
EWS03
Service Outlet Panels
EW755, EW756, EW759, EW763, EW764, EW767
Lid
CTI3 (Inspection lid)
CTS3 (Service lid)
CTI43 (Inspection lid)
CTS43 (Service lid)
CTI43 (Inspection lid)
CTS43 (Service lid)
EWS043
EW103, EW105, EW106, EW109, EW113,
EW114, EW125
EW755, EW756, EW759, EW763, EW764, EW767
EWTG3
Type
EWTG43x3
EWTG43x4
WHAT TO ORDER
116
Product Finishing Key (See page 24)
EASY WAY FLUSH FLOOR TRUNKING SYSTEMS
