UNITRUNK EASY-WAY FLUSH FLOOR TRUNKING is designed to offer versatility within the
trunking layout, giving the end user the final option to ammend the position of the service
outlets. The Easy-Way system also permits the relocation or addition of service outlets
after the initial installation is complete.
INSTALLATIONS - Easy-way flush floor trunking is 65mm high trunking which can be installed into new builds
and existing installations. Here are some installation tips and best practices that should be considered when
planning and installing Easyway trunking products:
5. COMPACT & LEVEL - When
applying the screed, the screed
layer must be installed with care.
The screed should be compacted
to provide good static support of
the trunking system. Ensure the
screed is level with the trunking lid
to prevent line shadowing on any
final floor finish.
These diagrams are for guidance only. Unitrunk accepts no responsibility for any aspect of product installation.
1. ALLOW ACCESS (EXISTING INSTALLATIONS ONLY) - A level opening for the trunking should be cut in the screed
which allows access for tooling.
2. SOLID FOUNDATION - The trunking should be laid on a supporting screed ribbon or a support grout
approved by an architect or consultant.
3. LID SUPPORT - The galvanised lids and service outlet boxes should be in position when the screed is poured,
otherwise the pressure may distort the trunking sidewalls.
4. NO VOIDS - After final levelling of the trunking and before
coupling together, the screed or grout bedding should be fully
packed under the trunking to eliminate any voids, which could
result In soft spots of the trunking assembly.
