practical & easy to install
Order
Code
Input
Voltage
Lamp
Type
Power
Consumption
Operation /
Duration (hrs)
Recharge
Period
Environment Weight Includes
Legend
PX3LS1 220 - 240 Vac, 50 Hz 1 W LED strip 27 mA M3 24 hours 0 - 25 °C 1.0 kg
PXR3LS1 220 - 240 Vac, 50 Hz 1 W LED strip 27 mA M3 24 hours 0 - 25 °C 1.4 kg
PX1LS1HF 220 - 240 Vac, 50/60 Hz 1 W LED strip 30 mA 230 V - 0 - 40 °C 0.9 kg
PX1LS1LTC 220 - 240 Vac, 50/60 Hz 1 W LED strip 30 mA 230 V - 0 - 40 °C 1.3 kg
PXR1LS1HF 220 - 240 Vac, 50/60 Hz 1 W LED strip 30 mA 230 V - 0 - 40 °C 0.9 kg
PXR1LS1LTC 220 - 240 Vac, 50/60 Hz 1 W LED strip 30 mA 230 V - 0 - 40 °C 1.3 kg
LED base unit
Legends
Legends are screen printed. Euro pictogram legends shown. ISO 7010 format legends are available to order, see page 95 or contact Emergi-Lite.
Dimensions
287
136
72
240
256
207
30
Ø 12 mm (3x)
Cable entry points (3x)
Ø 10 mm
259
146
160
292
100
143 255
1-35
Ø13 (2x)
Edge-lit LED exit sign.
Ideal for use in commercial offices, hotels, public
buildings, cafes and retail units etc
Manufactured from high grade polycarbonate
in white
Straightforward installation, with first-fix base
Options for surface (PX) or recessed (PXR) mount
Intelligent self-test as standard
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in the UK
Order LED base unit and double sided exit sign kit
(PX/DSLKIT) separately
Single
sided
Double
sided
XE02PX XE03PX XE06PX XE05PX XE03PX / XE06PX
Accessories
Order Code Description
PX/DSLKIT Double sided exit sign kit, includes
For accessory drawings, see page 92.
For further information on Naveo emergency luminaire
testing format, see pages 73 - 75 or contact Emergi-Lite.
