high impact & modern
High power open area luminaire.
Robust contemporary design, ideal for offices,
warehouses and storage facilities
Choice of 8 W or 11 W fluorescent lamps
Attractive aluminium modular enclosure
(certified to IP65 and IP67)
Clear polycarbonate broad delivery diffuser
Includes light sensor for overnight security
lighting application
Intelligent Self-Test as standard
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in the Netherlands
For Aqualux spacing data, see page 86.
For accessory drawings, see page 92.
Order
Code
Input
Voltage
Lamp
Type
Lamp
Output
Power
Consumption
Operation /
Duration (hrs)
Recharge
Period
Environment Weight
OW23161 220 - 240 Vac, 50 Hz 8 W T5 156 lumens 40 mA NM3 24 hours 0 - 25 °C 2.0 kg
OW33161 220 - 240 Vac, 50 Hz 8 W T5 156 lumens 90 mA M3 24 hours 0 - 25 °C 2.2 kg
OW13161HF 220 - 240 Vac, 50/60 Hz 8 W T5 303 lumens 70 mA 230 V - 0 - 40 °C 1.8 kg
OW13161LTC 220 - 240 Vac, 50/60 Hz 8 W T5 303 lumens 70 mA 230 V - 0 - 40 °C 1.9 kg
OW26161 220 - 240 Vac, 50 Hz 11 W PL 252 lumens 40 mA NM3 24 hours 0 - 25 °C 2.0 kg
OW36161 220 - 240 Vac, 50 Hz 11 W PL 252 lumens 120 mA M3 24 hours 0 - 25 °C 2.2 kg
OW16161HF 220 - 240 Vac, 50/60 Hz 11 W PL 675 lumens 100 mA 230 V - 0 - 40 °C 1.8 kg
OW16161LTC 220 - 240 Vac, 50/60 Hz 11 W PL 675 lumens 120 mA 230 V - 0 - 40 °C 1.9 kg
Luminaire
Dimensions
Cable 7-13.4mm (3x)
320
Ø20 (2x)
110
381
170
75
Order Code Description
OW/BCM Ceiling bracket, vertical mount
OW/BWA Wall bracket, angled mount
OW/BWM Wall mount end cantilever bracket
Accessories
