125 / 156
Adaptaflex Product Catalogue |
LIT211GB 0715
6/9
6
Clamping Bush
Smooth Cable Guide
Materials:
Polyamide 6.6 /
Colour:
Black RAL 9005 (B)
Metric
Plug
Hexagon
Hole
Across Flats Pack
Part No.
Thread A
Length B
Thickness C Diameter D DImension E Quantity
46-B
M16
14mm
5mm
10.5mm
19mm
100
47-B
M20
18mm
6mm
13.0mm
23mm
100
48-B
M25
18mm
6mm
19.0mm
28mm
100
IP Rating
IP66
N/A
Approvals
Cable glands & terminal blocks
Clamping bush & Stopping plugs
Temperature Range
Static Applications: -10ºC to +90ºC
Flammability
UL94 - V2 (Nylon material)
Halogen Free
Yes
Clamping Bush
Stopping Plug
General Purpose IP66 Stopping Plug
Materials:
Polyamide 6.6 /
Colour:
Black RAL 9005 (B)
Metric
Across Flats Plug
Head
Pack
Part No.
Thread A
Dimension B Length C
Depth D
Quantity
64-B
M16
19mm
14mm
5mm
100
65-B
M20
23mm
18mm
6mm
100
66-B
M25
28mm
18mm
7mm
100
67-B
M32
36mm
19mm
3mm
100
Adaptaflex range of Stopping Plugs are ideal for sealing cable entries
IP Rating
IP66
N/A
Approvals
Temperature Range
Static Applications: -10ºC to +90ºC
Flammability
UL94 - V2 (Nylon material)
Halogen Free
Yes
Stopping Plug
D
C
A
D
C
B
A
Dimensions
Dimensions
B
E
D
