Miniature Gland
Small Cable Size IP66 Cable Gland
Materials:
Polyamide 6.6 with Nitrile Rubber Seal /
Colour:
Black RAL 9005 (B), White RAL 9010 (W) - Black Part Numbers Listed
Metric
Thread
Cable Max Cable Min
Gland
Gland
Across Flats Pack
Sealing
Locknut
Part No.
Thread A
Lengths B
Diameter
Diameter
Depth C
Diameter D Dimension E Quantity
Washer
Part No.
238
M10
8mm
5mm
2mm
21mm
17mm
15mm
100
68
78-B
240
M10
8mm
7mm
5mm
21mm
17mm
15mm
100
68
78-B
244
M10
20mm
5mm
2mm
21mm
17mm
15mm
100
68
78-B
246
M10
20mm
7mm
5mm
21mm
17mm
15mm
100
68
78-B
239
M13
8mm
5mm
2mm
21mm
17mm
15mm
100
69
79-B
241
M13
8mm
7mm
5mm
21mm
17mm
15mm
100
69
79-B
245
M13
20mm
5mm
2mm
21mm
17mm
15mm
100
69
79-B
247
M13
20mm
7mm
5mm
21mm
17mm
15mm
100
69
79-B
Miniature cable glands are ideal for small cable sizes and offer IP66 protection. To order quote part number & colour, e.g. 238-W
Miniature cable glands are available with either long or short threads. Locknuts and sealing washers are available as separate items
IP Rating
IP66
Yes
Approvals
Cable glands & terminal blocks
Miniature gland & Cord grip bush
Temperature Range
Static Applications: -20ºC to +90ºC
Flammability
UL94 - V2 (Nylon material)
Halogen Free
Yes
Miniature Gland
Cord Grip Bush
Cord Grip Entry Bush
Materials:
Polyamide 6.6 /
Colour:
Black RAL 9005 (B)
Metric
Thread
Cable Max Cable Min
Across Flats Overall
Pack
Sealing
Locknut
Part No.
Thread A
Lengths B
Diameter
Diameter
Dimension C Length D
Quantity
Washer
Part No.
743-B
M16
9mm
11mm
3.5mm
19mm
23.5mm
100
96
92-B
744-B
M20
12mm
14mm
4.0mm
23mm
29.5mm
100
97
93-B
745-B
M25
12mm
18mm
8.0mm
27mm
29.5mm
100
98
94-B
IP Rating
IP66
N/A
Approvals
Temperature Range
Static Applications: -20ºC to +90ºC
Flammability
UL94 - V2 (Nylon material)
Halogen Free
Yes
