121 / 156
Adaptaflex Product Catalogue |
LIT211GB 0715
6/5
6
Index A2P - Cable Gland
High Performance IP68 upto 15bar Cable Gland
/
Materials:
Polyamide 6.6 with Nitrile Rubber Seal
Colour:
Black RAL 9005 (B)
Metric
Thread
Gland Length Cable Max
Cable Min
Gland
Across Flats Pack
Sealing
Part No.
Thread A
Lengths B
Compressed C Diameter
Diameter
Diameter D Dimension E Quantity
Washer
Locknut
200-8160
M16
15mm
24mm
8.0mm
4.0mm
26.0mm
24mm
50
96
92-B
200-8240
M20
15mm
24mm
8.0mm
4.0mm
26.0mm
24mm
50
97
93-B
200-8320
M20
15mm
25mm
10.0mm
7.5mm
30.0mm
27mm
50
97
93-B
200-8400
M20
15mm
26mm
13.2mm
9.5mm
35.5mm
32mm
50
97
93-B
200-8560
M25
15mm
28mm
18.0mm
13.0mm
40.0mm
36mm
25
98
94-B
200-8640
M32
15mm
31mm
25.0mm
17.5mm
51.0mm
46mm
10
99
95-B
200-8720
M40
15mm
31mm
31.5mm
24.5mm
61.0mm
55mm
10
121
111-B
200-8800
M50
15mm
31mm
37.0mm
31.0mm
78.0mm
70mm
5
122
112-B
200-8880
M50
15mm
31mm
43.0mm
36.5mm
78.0mm
70mm
5
122
112-B
Index A2P Cable Gland
Cable glands & terminal blocks
Index A2P & Euro Index - cable glands
IP Rating
IP68
Yes (5 bar 30mins)
Approvals
Temperature Range
Static Applications: -20ºC to +90ºC
Key Features
– Smaller working envelope on bulkhead or panel
– Wide cable acceptance range for each gland size
– Integral claw design prevents cable twisting during installation
– Designed to EN 50262:1999
Flammability
UL94 - V2 (Nylon material)
Halogen Free
Yes
Euro Index - Cable Gland
IP68 Industrial 3 Part Plastic Cable Gland
/
Materials:
Polyamide 6.6 with Nitrile Rubber Seal
Colour:
Red RAL 3031 (R), White RAL 9010 (W), Grey RAL 7030 (G), Black RAL 9005 (B), Dark Grey RAL 7001 (DG)
Metric
Thread
Cable Max Cable Min
Gland
Gland
Across Flats Pack
Part No.
Thread A
Lengths B
Diameter
Diameter
Depth C
Diameter D Dimension E Quantity
ESM12-10
M12
8mm
6.5mm
2mm
23.0mm
19.0mm
17mm
100
ESM16-11
M16
9mm
10.0mm
4mm
25.5mm
23.5mm
21mm
100
ESM20-12
M20
10mm
12.0mm
6mm
27.0mm
27.0mm
24mm
100
ESM20-13
M20
10mm
14.0mm
10mm
28.5mm
30.0mm
27mm
100
ESM25-14
M25
11mm
18.0mm
13mm
29.0mm
33.0mm
30mm
100
ESM32-15
M32
12mm
25.0mm
17mm
37.0mm
45.5mm
41mm
50
ESM40-16
M40
13mm
32.0mm
24mm
42.0mm
55.5mm
50mm
25
To order quote part number & colour, e.g. ESM12-10B-LN
Euro Index - Cable Gland
D
E
A
B
C
Dimensions
