Index EMC Type A & B - cable glands
Index EMC Type A - Cable Gland
High Performance IP68 Cable Gland
/
Materials:
Nickel Plated Brass, Stainless Steel Spring, Rubber Seal (TPE-V)
Metric
Thread
Gland
Across Flats Cable Max
Cable Min
Screen
Screen
Pack
Locknut
Part No.
Thread A
Type
Lengths B
Diameter C Dimension D Diameter
Diameter
Dia. Max
Dia. Min
Quantity
Part No.
260-1050
M16
A
10mm
26.7mm
24mm
9mm
6m
7.5mm
3.5mm
1
260-0500
260-1100
M16
A
10mm
26.7mm
24mm
11mm
7mm
8.5mm
4mm
1
260-0500
260-1200
M20
A
10mm
26.7mm
24mm
9mm
6mm
7.5mm
3mm
1
260-0600
260-1250
M20
A
10mm
26.7mm
24mm
11mm
7mm
8.5mm
4mm
1
260-0600
260-1300
M25
A
11mm
33.5mm
30mm
9.5mm
6mm
8.5mm
6mm
1
260-0650
260-1350
M25
A
11mm
33.5mm
30mm
11mm
6mm
9.0mm
6mm
1
260-0650
260-1700
M32
A
13mm
43.5mm
40mm
26mm
22mm
21.0mm
15mm
1
260-0700
260-1750
M40
A
14mm
54.0mm
50mm
29mm
25mm
25.0mm
18mm
1
260-0750
260-1900
M50
A
15mm
65.0mm
60mm
41mm
37mm
33.0mm
29mm
1
260-0800
IP Rating
IP68
Yes (10 bar 30min)
Approvals
Temperature Range
Static Applications: -40ºC to +135ºC
Halogen Free
Yes
Index EMC Cable Gland
Index EMC Type B - Cable Gland
High Performance IP68 Cable Gland
/
Materials:
Nickel Plated Brass, Stainless Steel Spring, Rubber Seal (TPE-V)
Metric
Thread
Gland
Across Flats Cable Max
Cable Min Screen
Screen
Pack
Locknut
Part No.
Thread A
Type
Lengths B
Diameter C Dimension D Diameter
Diameter
Dia. Max
Dia. Min
Quantity
Part No.
260-1000
M16
B
10mm
26.7mm
24mm
6mm
4mm
6.0mm
3.0mm
1
260-0500
260-1150
M20
B
10mm
26.7mm
24mm
6mm
4mm
6.0mm
3.0mm
1
260-0600
260-1400
M25
B
11mm
33.5mm
30mm
11mm
6mm
10.5mm
6.0mm
1
260-0650
260-1450
M25
B
11mm
33.5mm
30mm
14mm
10mm
13.0mm
8.0mm
1
260-0650
260-1550
M25
B
11mm
33.5mm
30mm
18mm
14mm
17.5mm
12.5mm
1
260-0650
260-1650
M32
A/B
13mm
43.5mm
40mm
23mm
19mm
21.0mm
15.0mm
1
260-0700
260-1800
M40
B
14mm
54.0mm
50mm
32mm
29mm
30.5mm
24.0mm
1
260-0750
The INDEX Uni Iris range of cable glands are for use with screened cable and have been designed to connect the screen of the cable to the enclosure screening system
This is achieved by the use of two tapered rings applying force onto a continuous stainless steel spring washer pressing against the screen, ensuring positive contact
Assembly is simple, the screen is exposed, the spring and washers are slipped in place and then the gland can be tightened
Key Features
– Screen continues into enclosure
– IP68 Protection at 10 bar for 30 minutes
– Metric
– For use with systems conforming to EN50 082-1/2
Type A
– Stripped Cable Sheath - Allowing the outer sheath to
be completeley stripped from the cable
Type B
– Continuous Cable Sheath - Allowing for a ring of
outer sheath only to be stripped
D
C
A
B
Dimensions
