Non-metallic conduit systems
PVC Type A & C90 - RF
Type A - RF
Straight Fitting - Fixed External Male Thread
/
For insertion into threaded entries & knockouts. Locknuts supplied with METRIC THREAD ONLY
Materials:
Polyamide (Nylon) 66 /
Colour:
Black (BL) Only
Nominal
Metric
Part No.
Conduit Size Thread
RF12/M16/A 12mm
M16
RF16/M16/A 16mm
M16
RF16/M20/A 16mm
M20
RF20/M20/A 20mm
M20
RF25/M25/A 25mm
M25
RF32/M32/A 32mm
M32
To order quote part number, e.g. XF16/M16/D
Type A
Straight Fitting
Type C90 - RF
90º Elbow Fitting - Fixed External Male Thread
/
For insertion into knockouts. Locknuts supplied with METRIC THREAD ONLY
Materials:
Polyamide (Nylon) 66 /
Colour:
Black (BL) Only
Nominal
Metric
Part No.
Conduit Size Thread
RF16/M16/C90 16mm
M16
RF20/M20/C90 20mm
M20
RF25/M25/C90 25mm
M25
RF32/M32/C90 32mm
M32
To order quote part number, e.g. XF16/M16/C90
Type C90
90º Elbow Fitting
IP Rating
Appropriate Conduit
For use with:
Xtraflex Type RF
IP40
N/A
IP65
N/A
IP66
N/A
IP67
Yes
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -5ºC to +60ºC
Moving Applications: -5ºC to +60ºC
Fitting Characteristics
Approvals
IP Rating
Appropriate Conduit
For use with:
Xtraflex Type RF
IP40
N/A
IP65
N/A
IP66
N/A
IP67
Yes
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -5ºC to +60ºC
Moving Applications: -5ºC to +60ºC
Approvals
