Non-metallic conduit systems
Type PK & A - Peek
Polyetherketone Type PK - Peek
High Specification Conduit
/
Materials:
Polyetherketone /
Colour:
Black (BL) Only
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PKFS13
13mm
10
Fine
13.2mm
10.0mm
35mm
25, 50m
PKFS16
16mm
13
Fine
16.3mm
11.7mm
45mm
25, 50m
PKFS21
21mm
17
Fine
21.2mm
16.6mm
60mm
25, 50m
PKCS28
28mm
23
Coarse
28.4mm
21.7mm
65mm
25, 50m
PKCS34
34mm
29
Coarse
34.3mm
27.7mm
80mm
25, 50m
To order quote part number, colour & reel length, e.g. PKFS16/BL/50M
Temperature Range
Static Applications: -60ºC to +260ºC
Moving Applications: -45ºC to +260ºC
Flexibility & Fatigue Life
High Flexibility - High Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
Approvals
Type PK
High Specification Conduit
IP Rating
Appropriate Fitting
For use with:
Peek Type A
IP40
N/A
IP65
N/A
IP66
Peek Type A
IP67
Peek Type A
IP68
N/A
IP69K
N/A
IP Rating
Appropriate Conduit
For use with:
Peek Type PK
IP40
N/A
IP65
N/A
IP66
Yes
IP67
Yes
IP68
N/A
IP69K
N/A
Type A - Peek
Straight Fitting - Fixed External Male Thread
/
For insertion into knockouts using a locknut
Materials:
Nickel Plated Brass & Silicone
Nominal
Metric
Part No.
Conduit Size Thread
PK13/M16/A 13mm
M16
PK16/M16/A 16mm
M16
PK21/M20/A 21mm
M20
PK28/M25/A 28mm
M25
PK34/M32/A 34mm
M32
Temperature Range
Static Applications: -60ºC to +260ºC
Moving Applications: -45ºC to +260ºC
Fire Performance & EMI Screen
Approvals
Type A
Straight Fitting
