Adaptaflex Product Catalogue |
LIT211GB 0715
2
Non-metallic conduit systems
Type PKTC & PKSS - Hi-Spec
Type PKTC - Hi-Spec
High Specification, High EMI Screening Conduit
Materials:
Polyetherketone Conduit, Tinned Copper Overbraid
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PKFSTC13
13mm
10
Fine
14.1mm
10.0mm
35mm
25, 50m
PKFSTC16
16mm
13
Fine
17.2mm
11.7mm
45mm
25, 50m
PKFSTC21
21mm
17
Fine
23.6mm
16.6mm
60mm
25, 50m
PKCSTC28
28mm
23
Coarse
30.0mm
21.7mm
65mm
25, 50m
PKCSTC34
34mm
29
Coarse
36.0mm
27.7mm
80mm
25, 50m
To order quote part number & reel length, e.g. PKFSTC13/50M
Type PKTC
High Specification,
High EMI Screening Conduit
Type PKSS - Hi-Spec
High Specification, Standard EMI Screening Conduit
Materials:
Polyetherketone Conduit, Stainless Steel Overbraid
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PKFSSS13
13mm
10
Fine
14.1mm
10.0mm
35mm
25, 50m
PKFSSS16
16mm
13
Fine
17.2mm
11.7mm
45mm
25, 50m
PKFSSS21
21mm
17
Fine
23.6mm
16.6mm
60mm
25, 50m
PKFSSS28
28mm
23
Coarse
30.0mm
21.7mm
65mm
25, 50m
PKFSSS34
34mm
29
Coarse
36.0mm
27.7mm
80mm
25, 50m
To order quote part number & reel length, e.g. PKFSSS13/50M
Approvals
Type PKSS
High Specification,
Standard EMI Screening Conduit
Approvals
IP Rating
Appropriate Fitting
For use with:
Hi-Spec Type A & B
IP40
N/A
IP65
N/A
IP66
Hi-Spec Type A & B
IP67
Hi-Spec Type A & B
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -60ºC to +260ºC
Moving Applications: -45ºC to +260ºC
Flexibility & Fatigue Life
High Flexibility - High Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
IP Rating
Appropriate Fitting
For use with:
Hi-Spec Type A & B
IP40
N/A
IP65
N/A
IP66
Hi-Spec Type A & B
IP67
Hi-Spec Type A & B
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -60ºC to +260ºC
Moving Applications: -45ºC to +260ºC
Flexibility & Fatigue Life
High Flexibility - High Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
