Adaptaflex Product Catalogue |
LIT211GB 0715
2
Non-metallic conduit systems
Polypropylene Type PP & PPA - Adaptalok
Polypropylene Type PP - Adaptalok
Medium Weight Conduit
/
Materials:
Polypropylene /
Colour:
Black (BL) Only
Nominal
NW
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Diameter
Diameter
Radius
Length
PPFM13
13mm
10
13.0mm
9.8mm
5mm
50m
PPFM16
16mm
13
15.8mm
12.1mm
35mm
50m
PPFM21
21mm
17
21.2mm
16.8mm
40mm
50m
PPFM28
28mm
23
28.5mm
23.1mm
60mm
50m
PPFM34
34mm
29
34.5mm
29.1mm
50mm
50m
To order quote part number, colour & reel length, e.g. PPFM16/BL/50M
Temperature Range
Static Applications: -20ºC to +90ºC
Moving Applications: -5ºC to +105ºC
Flexibility & Fatigue Life
High Flexibility - Medium Fatigue Life
UV Resistance
Medium
Approvals
Type PP
Medium Weight Conduit
IP Rating
Appropriate Fitting
For use with:
Polypropylene Type PP
IP40
N/A
IP65
N/A
IP66
Polypropylene Type PP
IP67
N/A
IP68
N/A
IP69K
N/A
IP Rating
Appropriate Conduit
For use with:
Polypropylene Type PPA
IP40
N/A
IP65
N/A
IP66
Yes
IP67
N/A
IP68
N/A
IP69K
N/A
Polypropylene Type PPA - Adaptalok
Straight Fitting - Fixed External Male Thread
/
For insertion into knockouts using locknuts. Locknuts supplied
Materials:
Polypropylene /
Colour:
Black (BL) Only
Nominal
Metric
Part No.
Conduit Size Thread
AL13/M16/PPA 13mm
M16
AL16/M16/PPA 16mm
M16
AL21/M20/PPA 21mm
M20
AL28/M25/PPA 28mm
M25
AL34/M32/PPA 34mm
M32
To order quote part number & body colour, e.g. AL21/M20/PPA/BL
Temperature Range
Static Applications: -20ºC to +90ºC
Moving Applications: -5ºC to +105ºC
Fitting Characteristics
Approvals
Type PPA
Straight Fitting
