PowerSafe – Commercial & Industrial
13
Type ‘B’ General Characteristics
IP Rating
Paint Specification
Conditional Short Circuit Rating
IP3X
RAL 7035 epoxy powder coating
25kA to BS EN 61439-3
Cable Capacities
125A
Switch Disconnector
100A RCCB
Enclosure Earth Stud
Incoming earth terminal
Incoming neutral terminal
Outgoing earth terminal
Outgoing neutral ternal
50mm
2
50mm
2
M8
50mm
2
50mm
2
25mm
2
25mm
2
125A Type B TPN Distribution Boards
Quality features
s Removable door with easy align hinge design, to aid installation
s Cable trunking gasket included with every board to speed installation
s Multifunction, MID approved metered options as standard
s Metered boards are fully integrated, wired and ready to install
s SPSN, TPN, & TPSN incomer options
s Rigid construction, even with gland plates removed to reduce distortion during installation
s Full form MCB blanking modules for unused ways for increased electrical safety
s Door barrel lock accessory for increased security
General characteristics
Developed to meet the evolving Electrical Distribution
requirements in modern Commercial and Industrial
buildings, the new Havells type ‘B’ board delivers
a high performance, easy to install solution.
Performance tested with a conditional short circuit
rating of 25kA to BS EN 61439-3, the range is
complimented by a range of accessories including
Surge protection solutions and metering options.
