PowerSafe – Commercial & Industrial
9
Type ‘A’ SPN Distribution Boards
Quality features
s Door opening to 180° for easy access
s Robust 2mm gland plates are removable to aid installation
s Main busbar is removable to aid installation when required
s Fully shrouded Neutral for increased safety
s Rigid construction, even with gland plates removed to reduce distortion during installation
s Full form MCB blanking modules for unused ways for increased electrical safety
s Door barrel lock accessory for increased security
General characteristics
Developed to meet the evolving Electrical
Distribution requirements in modern Commercial
and Industrial buildings, the new Havells type ‘A’
board delivers a high performance, easy to install
solution. Performance tested with a conditional
short circuit rating of 15kA to BS EN 60439, the
range is complimented by a range of accessories
including Surge protection solutions and metering
options.
Type ‘A’ General Characteristics
IP Rating
Paint Specification
Conditional Short Circuit Rating
IP3X
RAL 7035 epoxy powder coating
15kA to BS EN 61439-3
Cable Capacities
100A Switch Disconnector
100A RCCB
Enclosure Earth Stud
Incoming earth terminal
Incoming neutral terminal
Outgoing earth terminal
Outgoing neutral terminal
35mm
2
35mm
2
M6
25mm
2
50mm
2
25mm
2
25mm
2
