PowerSafe – Commercial & Industrial
19
250A Type B TPN Distribution boards
Quality features
s Bolted earth, neutral and phase connections suitable for larger cables
s Removable door with easy align hinge design, to aid installation
s Cable trunking gasket included with every board to speed installation
s Integral metering options available
s TPN, & TPSN incomer options
s Rigid construction, even with gland plates removed to reduce distortion
during installation
s Full form MCB blanking modules for unused ways for increased electrical safety
s Door barrel lock accessory for increased security
B Type General Characteristics
IP Rating
Paint Specification
Conditional Short Circuit Rating
IP3X
RAL 7035 epoxy powder coating
25kA to BS EN 61439-3
Cable Capacities
250A
Switch Disconnector
Enclosure Earth Stud
Incoming earth terminal
Incoming neutral terminal
Outgoing earth terminal
Outgoing neutral ternal
120mm
2
(M8)
M8
50mm
2
50mm
2
25mm
2
25mm
2
General characteristics
Specifically designed to address applications
requiring electrical supplies larger than 125A the
250A Type B distribution board range also features
an optional add-on high current MCB extension
box designed for outgoing circuits above 63A. This
unique combined solution offers a cost effective
alternative to an MCCB panelboard where only one
or two outgoing circuits are required. The range is
complimented by a range of accessories including
Surge protection, MID metering and NEW earth
leakage monitoring solutions for compliance with
local UK regulations.
